NTE519 Silicon Rectifier Diode Ultra Fast Switch Absolute Maximum Ratings: Repetitive Peak Reverse Voltage, V 100V RRM Reverse Voltage, V 75V R Surge Forward Current (t = 1 s), I . 2A p FSM Repetitive Peak Forward Current, I . 500mA FRM Forward Current, I 300mA F Average Forward Current (V = 0), I 150mA R FAV Power Dissipation (I = 4mm), P V T = +45C 440mW L T +25C 500mW L Junction Temperature, T . +200C J Storage Temperature Range, T 65 to +200C stg Junction to Ambient (I = 4mm, T = constant), R 350K/W L thJA Electrical Characteristics: (T = +25C unless otherwise specified) J Parameter Symbol Test Conditions Min Typ Max Unit Forward Voltage Drop V I = 10mA 1 V F F Reverse Current I V = 20V 25 nA R R V = 20V, T = +150C 50 A R J V = 75V 5 A R Breakdown Voltage V I = 100 A, Note 1 100 V (BR) R Diode Capacitance C V = 0, f = 1MHz, V = 50mV 4 pF D R HF Rectification Efficiency V = 2V, f = 100MHz 45 % r HF Reverse Recovery Time t I = I = 10mA, i = 1mA 8 ns rr F R R I = 10mA, V = 6V, i = 0.1 I , R = 100 4 nS F R R R L t p = 0.01, t = 0.3ms Note 1. p T 1.000 .200 (25.4) (5.08) Min Max .022 (.509) Dia Max .090 (2.28) Dia Max Color Band Denotes CathodeX-ON Electronics Largest Supplier of Electrical and Electronic Components Click to view similar products for NTE manufacturer: Other Similar products are found below : 747 797 868 1724 NEH680M50FE NEHH1.0M450CB NTE131 NTE48 NTE526A 228A 231 954 2023 510 WH20-04-25 04- SLPE3750A 5615 591 MJ10012 7056 7448 NEH.10M50AA NEH2.2M63AA NEH330M35DD NEH33M10AA NEV.22M100AA NTE133 NTE542 NTE74154 04-SCBW25L-BK 04-SCBW6C-BK 04-SCBW32L-BK 04-SCW10C-BK 04-SCBW19L-GR 04-SCW19L- WH 04-SCW19L-OR 04-SCW38L-WH 04-SCBW50L-OR 04-SCBW50L-GR 04-SCW10C-GR 04-SCW10C-OR 04-SCBW32L-GR 04- SCBW32L-WH 04-SCBW32L-OR 04-SCBW6C-WH 04-SCBW6C-GR 04-SCBW6C-OR 04-SCBW25L-GR 04-SCBW25L-WH 04-ESNF- 500L
