Heat Shrink Tubing Thin Wall, 2:1 Shrink Ratio (Includes Assortment Packs) Description: NTEs Thin Wall Heat Shrink Tubing is a high performance, multi purpose, professional grade, flexible, flame retardant, polyolefin based heat shrinkable tubing with excellent electrical, chemical and physical properties. This tubing is used extensively in industrial and military applications for cable and wire harnessing, strain relief, insulation, color coding, identification and protection against fluids. Specifications: MILDTL 23053/5, Class 1 and 3, CSA C22.2 No 198.1 UL 224, 125 C, VW1 (Except Clear) Features: Available in Black, Blue, Red, Green, Yellow, White, Clear, Brown, Grey, Orange and Violet Also available in assorted packages Technical Data: Properties Test Method Typical Value Physical 2 Tensile Strength ASTM D 638 13 N/mm Elongation at Break ASTM D 638 400% Longitudinal Change ASTM D 2671 +5%, 5% Maximum Water Absorption ASTM D 570 0.15% Maximum Specific Gravity ASTM D 792 1.4 Chemical Fungus Resistance MIL17444 Inert Fluid Resistance MIL123053/5 Good Copper Corrosion ASTM D 2671 B Good Thermal Continuous Operating Temperature 55 to +135 C Minimum Shrink Temperature > +90 C Heat Shock (4 Hours at +250 C) ASTM D 2671 No Dripping, Cracking or Flowing Heat Aging (168 Hours at +150 C) ASTM D 638 Elongation 300% Low Temperature Flexibility (55 C) ASTM D 2671 C No Cracking Flammability UL 224 VW 1 Pass (Except Clear) Electrical Voltage Rating 600V Dielectric Strength ASTM D 2671 25kV/mm Volume Resistivity ASTM D 257 10 14 ohm.cm Rev. 415Products Covered: (Note 1, Note 2) Rec. Wall NTE Catalog Number I.D. (in mm) Thickness Size 100 Spool 50 Spool 25 Spool 48 6 Exp. Rec. (mm) (inch) Qty/Pkg 47100100XX 4710050XX 4720048XX 4720006XX 30 3/64 1.2 0.6 0.43 47101100XX 4710150XX 4720148XX 4720106XX 30 1/16 1.6 0.8 0.43 47102100XX 4710250XX 4720248XX 4720206XX 30 3/32 2.4 1.2 0.51 47103100XX 4710350XX 4720348XX 4720306XX 30 1/8 3.2 1.6 0.51 47104100XX 4710450XX 4720448XX 4720406XX 25 3/16 4.8 2.4 0.52 47105100XX 4710550XX 4720548XX 4720506XX 20 1/4 6.4 3.2 0.65 47106100XX 4710650XX 4720648XX 4720606XX 15 5/16 7.9 4.0 0.65 47107100XX 4710750XX 4720748XX 4720706XX 15 3/8 9.5 4.7 0.65 47108100XX 4710850XX 4720848XX 4720806XX 12 1/2 12.7 6.4 0.65 47109100XX 4710950XX 4710925XX 4720948XX 4720906XX 10 3/4 19.1 9.5 0.77 47110100XX 4711050XX 4711025XX 4721048XX 4721006XX 7 1 25.4 12.7 0.89 47111100XX 4711150XX 4711125XX 4721148XX 4721106XX 4 1 1/2 38.1 19.1 1.00 47112100XX 4711250XX 4711225XX 4721248XX 4721206XX 3 2 50.8 25.4 1.10 Note 1. Replace XX with: BK = Black, BL = Blue, R = Red, G = Green, Y = Yellow, W = White, CL = Clear, BR = Brown, GR = Grey, OR = Orange and VT = Violet. Note 2. Premium colors (Brown, Grey, Orange and Violet) are only available in 48 lengths and in sizes from 3/64 up to 1. Assorted Thin Wall Packages: Diameter Length NTE Part No. Color (Inches) (Inches) Pieces Bag/Box HSASST1 Black 3/32, 1/8, 3/16, 1/4, 3/8, 1/2 6 24 Bag (4 Pieces of Each Diameter) HSASST2 Black 1/16 (60 Pieces), 1/8 (40 Pieces), 2 1/2 158 Box 3/16 (20 Pieces), 1/4 (18 Pieces), 3/8 (10 Pieces), 1/2 (10 Pieces) HSASST3 Red 1/16 (60 Pieces), 1/8 (40 Pieces), 2 1/2 158 Box 3/16 (20 Pieces), 1/4 (18 Pieces), 3/8 (10 Pieces), 1/2 (10 Pieces) HSASST4 Black 1/16 , 3/32, 1/8, 3/16, 1/4, 3/8, 1/2 4 28 Bag (4 Pieces of Each Diameter) HSASST5 (2) Black, (2) Red, (2) Clear, 1/8 6 10 Bag (1) Green, (1) Blue, (1) Yellow, (1) White HSASST6 (2) Black, (2) Red, (2) Clear, 3/16 6 10 Bag (1) Green, (1) Blue, (1) Yellow, (1) White HSASST7 (2) Black, (2) Red, (2) Clear, 1/4 6 10 Bag (1) Green, (1) Blue, (1) Yellow, (1) White HSASST8 (2) Black, (2) Red, (2) Clear, 3/8 6 10 Bag (1) Green, (1) Blue, (1) Yellow, (1) White HSASST9 Black, Red, Clear, Green, 1/16 (60 Pieces), 3/32 (35 Pieces), 4 160 Box Blue, Yellow, White 1/8 (25 Pieces), 3/16 (20 Pieces), 1/4 (10 Pieces), 3/8 (10 Pieces) HSASST10 (2) Black, (2) Red, (2) Clear, 1/16 6 10 Bag (1) Green, (1) Blue, (1) Yellow, (1) White
