NTE5165A NTE

NTE5111A thru NTE5166A Zener Diode, 5 Watt 5% Tolerance Features: Zener Voltage: 3.3V to 200V High Surge Current Capability Absolute Maximum Ratings: DC Power Dissipation (T = +75C, Lead Length = 3/8), P . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5W L D Derate Above 75C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40mW/C Forward Voltage (I = 1A), V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2V F F Operating Junction Temperature Range, T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65 to +200C J Storage Temperature Range, T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65 to +200C stg Electrical Characteristics: (T = +25C unless otherwise specified) A Max Reverse Nominal Max Max Zener Impedance Leakage Current Zener Voltage Max Surge Max Test Voltage Current Regulation Regulator Z I Z I = 1mA ZT ZT ZK ZK V I Current i V Current Z ZT r Z (Note 1) (Note 1) I V I R R (Note 1) (Note 2) (Note 3) I ZT ZM Volts mA A Volts Amps Volt mA NTE5111A 3.3 380 3.0 400 300 1 20 0.85 1440 NTE5112A 3.6 350 2.5 500 150 1 18.7 0.8 1320 NTE5113A 3.9 320 2 500 50 1 17.6 0.54 1220 NTE5114A 4.3 290 2 500 10 1 16.4 0.49 1100 NTE5115A 4.7 260 2 450 5 1 15.3 0.44 1010 NTE5116A 5.1 240 1.5 400 1 1 14.4 0.39 930 NTE5117A 5.6 220 1 400 1 2 13.4 0.25 865 NTE5118A 6.0 200 1 300 1 3 12.7 0.19 790 NTE5119A 6.2 200 1 200 1 3 12.4 0.1 765 NTE5120A 6.8 175 1 200 10 5.2 11.5 0.15 700 NTE5121A 7.5 175 1.5 200 10 5.7 10.7 0.15 630 NTE5122A 8.2 150 1.5 200 10 6.2 10 0.2 580Electrical Characteristics (Contd): (T = +25C unless otherwise specified) A Max Reverse Nominal Max Max Zener Impedance Leakage Current Zener Max Surge Voltage Max Test Voltage Current Regulation Regulator Z I Z I = 1mA Current ZT ZT ZK ZK V I i V Current Z ZT r Z (Note 1) (Note 1) I V (Note 1) I R R (Note 3) (Note 2) I ZT ZM Volts mA A Volts Amps Volt mA NTE5123A 8.7 150 2 200 10 6.6 9.5 0.2 545 NTE5124A 9.1 150 2 150 7.5 6.9 9.2 0.22 520 NTE5125A 10 125 2 125 5 7.6 8.6 0.22 475 NTE5126A 11 125 2.5 125 5 8.4 8 0.25 430 NTE5127A 12 100 2.5 125 2 9.1 7.5 0.25 395 NTE5128A 13 100 2.5 100 1 9.9 7 0.25 365 NTE5129A 14 100 2.5 75 1 10.6 6.7 0.25 340 NTE5130A 15 75 2.5 75 1 11.5 6.3 0.25 315 NTE5131A 16 75 2.5 75 1 12.2 6 0.3 295 NTE5132A 17 70 2.5 75 0.5 12.9 5.8 0.35 280 NTE5133A 18 65 2.5 75 0.5 13.7 5.5 0.4 265 NTE5134A 19 65 3 75 0.5 14.4 5.3 0.4 250 NTE5135A 20 65 3 75 0.5 15.2 5.1 0.4 237 NTE5136A 22 50 3.5 75 0.5 16.7 4.7 0.45 216 NTE5137A 24 50 3.5 100 0.5 18.2 4.4 0.55 198 NTE5138A 25 50 4 110 0.5 19 4.3 0.55 190 NTE5139A 27 50 5 120 0.5 20.6 4.1 0.6 176 NTE5140A 28 50 6 130 0.5 21.2 3.9 0.6 170 NTE5141A 30 40 8 140 0.5 22.8 3.7 0.6 158 NTE5142A 33 40 10 150 0.5 25.1 3.5 0.6 144 NTE5143A 36 30 11 160 0.5 27.4 3.3 0.65 132 NTE5144A 39 30 14 170 0.5 29.7 3.1 0.65 122 NTE5145A 43 30 20 190 0.5 32.7 2.8 0.7 110 NTE5146A 47 25 25 210 0.5 35.8 2.7 0.8 100 NTE5147A 51 25 27 230 0.5 38.8 2.5 0.9 93 NTE5148A 56 20 35 280 0.5 42.6 2.3 1 86 NTE5149A 60 20 40 350 0.5 42.5 2.2 1.2 79 NTE5150A 62 20 42 400 0.5 47.1 2.1 1.35 76 NTE5151A 68 20 44 500 0.5 51.7 2 1.5 70 NTE5152A 75 20 45 620 0.5 56 1.9 1.6 63 NTE5153A 82 15 65 720 0.5 62.2 1.8 1.8 58 NTE5154A 87 15 75 760 0.5 66 1.7 2 54.5 NTE5155A 91 15 75 760 0.5 69.2 1.6 2.2 52.5 NTE5156A 100 12 90 800 0.5 76 1.5 2.5 47.5 NTE5157A 110 12 125 1000 0.5 83.6 1.4 2.5 43 NTE5158A 120 10 170 1150 0.5 91.2 1.3 2.5 39.5
