Accessories Controllers 776GSp6ec-330..0545762283..32220110 c ooling Accessories c ontrollers Thermos TAT c onTroller FeATUres S aves energy, reduces filter replacement frequency and extends filter fan life T erminal block connection 3 8-mm DIN rail mounting bracket (according to EN 60715) and screws included Finish R AL7035 light gray Plastic housing UL94 V-0 no Tes c aution: When setting the temperature of the break contact (NC) and the changeover contact (CO) to use it as a break contact, care must be taken to add the maximum hysteresis (that consists of the switching difference and the operating tolerance) to the required minimum temperature. For instance, if the temperature in the enclosure may not fall below 5 C, the controller must be set to 5+7+3=15 C (with a switching) difference of 4-7 k and tolerance of +/- 3 k. Performance Data Thermostat c ontroller cATAlog nUmBers TWR60 Design DATA Control Range (F / C) -4 / -20 to 104 / 40 or 32 / 0 to 140 / 60 or 68 / 20 to 176 / 80 (see type plate) Switching Differences: Bimetal controllers Approx. 1 k, approx. 3 k, 4-7 k (see type plate) Capillary controllers less than 7 k Contact Snap contact as break contact = NC Make contact = NO Changeover contact = CO (see type plate) Switching Capacity: Break contact/make contact 100V250V / 10(2)A, at 4 max. 30 W Changeover contact - heating 100V250V / 10(2)A, at 4 max. 30 W Changeover contact - cooling 100V250V / 15(2)A, at 4 max. 30 W supply Voltage c ontroller (co ) requires 230V Protection IP20 Switchpoint Tolerance +/- 3k Sensor Bimetal 2 Power Connection Terminal screws 0.5 to 2.5 mm Bimetal Controller Ambient Temperature: T40 -4 / -20 to 104 / 40 T60 32 / 0 to 140 / 60 T80 68 / 20 to 176 / 80 Storage Temperature (F / C) -4 / -20 to 140 / 60 UniT consTrUcTion Unit Dimensions - H x W x D (in. / mm) 2.52 x 1.46 x 1.81 / 64 x 37 x 46 Weight (oz / g) 1.8 / 50 1 c ooling SUBJECT TO CHANGE WITHOUT NOTICE EQUIPMENT PROTECTION SOLUTIONS Spec-00583 GAccessories Controllers DUAl Thermos TAT inDU s Tr Y s TAnDA r Ds cURus File No. E164102 CSA File No. 215952 CE APPlic ATion Two thermostats in one, the Dual Thermostat independently controls equipment heating and cooling systems. FeATUres Two thermostats one normally closed (NC), red, and one normally open (NO), blue, in one casing Wide adjustable temperature range (32 -140 F) Thermostatic bimetallic sensor element 2 Connection: 4-pole terminal for AWG 14 max (2.5 mm ) Mounting clip for 35-mm DIN rail Finish Light-gray plastic, UL94V-0 Performance Data Dual Thermostat cATAlog nUmBers ADLTEMP elecTricAl DATA Switching Capacity (Normally Closed) 10 A resistive/2 A inductive 250 VAC, DC 30 W Switching Capacity - Normally Open 5 A resistive/2 A inductive 250 VAC, DC 30 W Setting Range - Normally Closed (F/C) 32/0 to 140/60 Setting Range - Normally Open (F/C) 32/0 to 140/60 UniT consTrUcTion Unit Dimensions - H x W x D (in./mm) 2.64/67 x 1.97/50 x 1.81/46 EQUIPMENT PROTECTION SOLUTIONS PH 763.422.2211 FAX 763.576.3200 HOFFMANONLINE.COM c ooling 2 Spec-00583 G
