Connector Accessories For Miniature Size Connectors Wire wraps neatly around caddy body. SMP-SC Wire Caddy (Spool Cap) wire caddy shown with SMP-T-M To Order Visit omega.com/smp-sc mini conn acc for Pricing and Details Model No. Compatible Connectors Write-on SMP-SC pkg of 5 SMPW, HMPW Window SWHCL pkg of 20 SMPW, HMPW SWHCL wire caddy shown with SMPW-K-M Dual Element Tube Clamp DX-BRLK-(*)-SMP dual element Model No. Compatible Connectors tube clamp shown with DX-BRLK-(*)-SMP SMPW, HMPW two SMP-J-M 1 1 *Insert probe diameter: 116 for 16 , or 18 for 8 Ferrite Cable Clamp Model No. Compatible Connectors PCLM-SMP-FT SMPW, GMP, HGMP For miniature connectors with PCLM-SMP-RSC-FT HMPW, MTP built-in ferrite, please visit omega.com, ferrite core included. Cable Clamp Model No. Compatible Connectors PCLM-SMP SMPW, HMPW PCLM-NMP NMP PCLM-GMP GMP, HGMP PCLM-SMP-RSC SMPW, HMPW (larger size wire) PCLM-SMP cable clamp shown with SMPW-J-M PCLM-SHX SHX-MF Miniature Strain Relief Tubing Model No. Compatible Connectors MSRT-116-(*) SMPW, HMPW, MSRT-332-(*) GMP, HGMP MSRT-532-10 *Insert quantity: select from packages of 5, 10, 50, 100. Center number denotes 3 3 5 tubing inside diameter: 316 for 16 , 332 for 32 , 532 for 32 . Rubber Boots Model No. Compatible Connectors MRB SMPW, HMPW MRBS SMPW, HMPW MRB rated to 200 MRBS rated to 450 G-332.54 (0.10) 15.75 5.334 (0.62) (0.120) 2.54 Connector Accessories (0.10) 2.54 (0.10) For Miniature Size Connectors Safety clip SMCL Shown with GMP-T-MF Safety Clip 15.75 5.334 (0.62) (0.120) To Order Visit omega.com/smp-sc mini conn acc for Pricing and Details 2.54 (0.10) Model No. Compatible Connectors SMCL SMPW, GMP, HMPW, HGMP FMCL FMP, FMPW, HFMP, HFMPW 19.05 (0.75) 9.525 (0.375) A Panel Mounting Bracket (Standard and Round Hole) A Model No. Compatible Connectors Dimension A SMACL SMPW, GMP, HMPW, HGMP 0.88 19.05 (0.75) MACL NMP 0.88 9.525 (0.375) SRMACL SMPW, GMP, HMPW, HGMP 0.67 SRMACL round hole SMACL panel RMACL NMP 0.67 panel mounting bracket. mounting bracket. G 19.05 (0.75) RB-SMP-100 wire Wire Hole ReducerFor Smaller Gauge Wires hole reducers shown SMPW Connectors with SMPW-K-M Model No. Pkg of 20 Reduced Hole Opening 7.92 (0.312) 1.575 RB-SMP-100 2.54 (0.100 ) Dia. (0.062) RB-SMP-140 3.55 (0.140 ) Dia. 19.05 (0.75) Dimensions: mm (inch) 7.92 (0.312) 1.575 (0.062) 1.27 (0.050) Crimp Style Bushing Dia A-ID Dia B-OD Dia C Dia E Compatible 1.27 Model Number mm (in) mm (in) mm (in) mm (in) Connectors ( ) Insert B for brass or (0.050) * S for stainless steel (*)B-SMP-CR020-(**) 0.56(0.022) 2.95 (0.116) 3.25 (0.128) 4.72 (0.186) ( ) Insert quantity: 10 ** or 100. CR number (*)B-SMP-CR032-(**) 0.89 (0.035) 2.95 (0.116) 3.25 (0.128) 4.72 (0.186) indicates compatible SHX, NMP, probe diameter. (*)B-SMP-CR040-(**) 1.09 (0.043) 2.95 (0.116) 3.25 (0.128) 4.72 (0.186) MTP, GMP, To order crimping tool for (*)B-SMP-CR1.5MM-(**) 1.57 (0.062) 2.95 (0.116) 3.25 (0.128) 4.72 (0.186) use with these bushings, SMP, SMPW, specify model number (*)B-SMP-CR062-(**) 1.65 (0.065) 2.95 (0.116) 3.25 (0.128) 4.72 (0.186) FMPW BB-SMT-CT. (*)B-SMP-CR093-(**) 2.44 (0.096) 4.72 (0.186) 3.96 (0.156) N/A (*)B-SMP-CR3.0mm-(**) 3.10 (0.122) 4.72 (0.186) 3.96 (0.156) N/A (*)B-SMP-CR125-(**) 3.25 (0.128) 4.72 (0.186) 3.96 (0.156) N/A Ordering Example: SB-SMP-CR040-100, pkg of 100 crimp style stainless steel bushing for 0.043 Dia. probe. Patented Covered by U.S. and International patents and Clamp Grommets Silicone 0.25 long pending applications. Inside Outside Compatible Model No. Diameter Diameter Length Connectors SSRT-CC-018-(*) 3.18 (0.125) OSTW SSRT-CC-332-(*) 2.38 (0.094) 4.77 6.35 male or (0.188) (0.250) SSRT-CC-116-(*) 1.59 (0.063) female SSRT-CC-132-(*) 0.79 (0.032) Insert pkg quantity: select from packages of 5, 10, 50, 100. * Center number denotes grommet inside diameter for 0.75 long strain relief tubing, visit omega.com G-34
