G6K Surface Mounting Relay Surface Mounting Relay with the Worlds Smallest Mounting Area Subminiature model as small as 5.2 (H) 6.5 (W) 10 (L) mm is ideal for high-density mounting (G6K(U)-2F(-Y)). Low profile of 5.2 mm improves mounting efficiency (G6K(U)-2F(-Y)). Light weight of 0.7 g contributes to higher speed mounting. Surface mounting terminal models incorporate a unique terminal structure with high infrared irradiation efficiency which allows the terminal temperature to rise easily when mounting the IRS, thus ensuring excellent soldering. Ensures a dielectric strength of 1,500 VAC and conforms to FCC Part 68 (i.e., withstanding an impulse withstand voltage of 1,500 V for 10 160 s). -Y models offer an impulse withstand voltage of 2,500 V for 2 10 s (conforms to Telcordia specifications) by optimizing the distance between coil and contacts. Standard model conforms to UL/CSA standards, certified by BSI (EN60950). Models available with a 2.54-mm terminal pitch. Rated carry current: 2A. RoHS Compliant G Model Number Legend 6 K G6K - - 123 4 1. Relay function None : Single-side stable model U : Single-winding latching model 2. Number of contact poles/Contact form 2 : 2-pole/DPDT (2c) 3. Terminal Shape F : Outside-L surface mounting terminals G : Inside-L surface mounting terminals P : PCB terminals 4. Terminal Arrangement - Impulse withstand voltage None :Terminal Arrangement 2.54 mm pitch Impulse withstand voltage Between coil and contacts (1.5 kV for 10 160 s) Y :Terminal Arrangement Between Coil-Contact Terminal 3.2 mm Between Contact Terminal 2.2 mm pitch Impulse withstand voltage Between coil and contacts (Conforms to Telcordia specifications: 2.5 kV for 2 10 s, 1.5kV for 10 160 s) Application Examples Telecommunication equipment Office automation machines Test and measurement equipment Building automation equipment Security equipment Industrial equipment Amusement equipment Home appliances 1G6K Surface Mounting Relay Ordering Information Surface Mounting Terminal Standard Models Packing Tube Packing Tape Packing Enclosure Relay Rated coil Minimum Rated coil Minimum Minimum ordering unit Contact form Model Model rating Function voltage packing unit voltage packing unit (tape packing) 3 VDC 3 VDC 4.5 VDC 4.5 VDC G6K-2F 5 VDC G6K-2F-TR 5 VDC 12 VDC 12 VDC 24 VDC 24 VDC 3 VDC 3 VDC 4.5 VDC 4.5 VDC Highly insulated Highly insulated G6K-2F-Y 5 VDC G6K-2F-Y-TR 5 VDC 12 VDC 12 VDC Single-side 24 VDC 24 VDC stable 3 VDC 3 VDC 4.5 VDC 4.5 VDC G6K-2G 5 VDC G6K-2G-TR 5 VDC 12 VDC 12 VDC 24 VDC 24 VDC Fully sealed DPDT (2c) 50 pcs/tube 900 pcs/reel 1,800 pcs/2 reels 3 VDC 3 VDC 4.5 VDC 4.5 VDC Highly insulated Highly insulated G6K-2G-Y 5 VDC G6K-2G-Y-TR 5 VDC 12 VDC 12 VDC 24 VDC 24 VDC G 3 VDC 3 VDC 6 4.5 VDC 4.5 VDC Highly insulated Highly insulated K G6KU-2F-Y 5 VDC G6KU-2F-Y-TR 5 VDC 12 VDC 12 VDC Single- 24 VDC 24 VDC winding 3 VDC 3 VDC latching 4.5 VDC 4.5 VDC Highly insulated Highly insulated G6KU-2G-Y 5 VDC G6KU-2G-Y-TR 5 VDC 12 VDC 12 VDC 24 VDC 24 VDC PCB Terminal Standard Models Rated coil Minimum Enclosure rating Relay Function Contact form Model voltage packing unit 3 VDC 4.5 VDC G6K-2P 5 VDC 12 VDC 24 VDC Single-side stable 3 VDC 4.5 VDC Highly insulated Fully sealed DPDT (2c) 5 VDC 50 pcs/tube G6K-2P-Y 12 VDC 24 VDC 3 VDC 4.5 VDC Single-winding Highly insulated 5 VDC latching G6KU-2P-Y 12 VDC 24 VDC Note 1. When ordering, add the rated coil voltage to the model number. Example: G6K-2F DC3 Rated coil voltage However, the notation of the coil voltage on the product case as well as on the packing will be marked as VDC. Note 2. When ordering tape packing, add -T to the model number. Be sure since -T is not part of the relay model number, it is not marked on the relay case. When ordering tape packing, minimum order unit is 2 reels (900 pcs 2 = 1,800 pcs). 2
