G2RV-SR G3RV-SR Common Precautions Common Accessories
Slim I/O Relay
G2RV-SR/G3RV-SR
Global standard size,
low profile slim I/O relay with width 6.2 mm,
slim I/O solid state relay
Realized about 25% lower profile than conventional
products, contributing to further miniaturization of the
control panel.
Push-In Plus technology are used to save wiring work in
comparison with conventional screw terminals.
(Wiring time is reduced by 60%* in comparison with
traditional screw terminals.)
For the recent information on models that have been certified
No screw loosening means maintenance-free application,
for safety standards, refer to your OMRON website.
realizing high reliability
Hand-free structure that holds an inserted flat-blade
screwdriver to achieve easier wiring work for stranded
wires.
Screw terminal is also stocked to meet the screw type
needs.
Mounted relay or solid-state relay has a plug-in terminal
that is difficult to bend at the time of exchange.
* According to OMRON actual measurement data from November 2015.
Refer to Safety Precautions on page 20.
Slim I/O Relay Types
G2RV-SR series mounted relay: electromagnetic relay ...... from page 2
G3RV-SR series mounted relay: solid state relay ................ from page 10
Common matter
Common precautions ................................................................ from page 20
Common accessories (order separately)................................. from page 24
1Common Precautions Common Accessories
G2RV-SR G3RV-SR
Slim I/O Relay
G2RV-SR
Global standard size, low profile slim
I/O relay with width 6.2 mm
Realized about 25% lower profile than conventional
products, contributing to further miniaturization of the
control panel.
Realized opening and closing ability with one pole 6 A slim
shape.
Micro load products for one pole 50 mA using Au-plated
contacts for small load switching also available.
Since G2RV is a transparent case, confirming the state of
the contact with the naked eye is possible, and easy to
confirm abnormality on-site (installed location).
For the recent information on models that have been certified
Screw terminal is also stocked to meet the screw type
for safety standards, refer to your OMRON website.
needs.
Mounted relay uses plug-in terminals that are difficult to
bend when exchanging.
Refer to Safety Precautions on page 20.
Features
Standard model/Micro load With latching lever Push-in plus technology
(Test switch)
Terminal x 5
Short bar insertion holes
Push-in plus
Protective cover
Screw
(Released state)
Operation Release hole
Release lever
display LED
Protective cover
Latching lever
(Socket section)
(Locked condition)
(Test switch) Terminal (insertion) hole
Latching lever
Mechanical
(Test switch)
indicator
Circuit check operation
Operation
Confirmation, reducing the inspection effort
verification
which is linked
to the contact PATForeign matter intrusion prevention structurMalfunction prevention stoppe
Transparent case
Relay contact
Easy confirmation
of the situation
Release lever
Relay easily
fixed/removed
90 mm
Plug-in terminal
Peace of mind as the
terminal does not bend
80 mm
when replacing
2
