ERJC1CFR016U Panasonic

Anti-Sulfurated High Power Chip Resistors / Wide Terminal Type ERJ C type ERJ C1 series Features High resistance to sulfurization achieved by adopting Anti-Sulfurated electrode material (Ag-Pd-based inner electrode) and structure (Covered electrode) High solder-joint reliability by wide terminal construction Excellent heat dissipation characteristics by wide terminal construction AEC-Q200 compliant RoHS compliant Recommended applications Motor control circuit of the industrial equipment Automotive electronic circuits including ECUs (Electrical control unit), anti-lock breaking systems and air-bag systems Current sensing for power supply circuits in a variety of equipment As for packaging methods, land pattern, soldering conditions and safety precautions, please see data files. Explanation of part numbers 1T ERJS02 ERJS1T 1 2 3 4 5 6 7 8 9 10 11 E R J 1 C F R 1 0 U Product rode Size,Power rating Code Resistance value region Resistance tolerance Resistance value Packaging methods Shown by 3 digits Code inch Power rating B 220 m R 1 Code Tolerance Code Packaging Part No. Thick film or letters. Only chip resistors C1 1020 2 W 10 m R< 220 m F 1 C Embossed carrier taping when it is U ERJC1 4 mm pitch, 5,000 pcs J 5 impossible, shown by 4 digits or letters. (Ex.) R01: 0.01 =10 m R015: 0.015 =15 m Ratings Category *1 Resistance Resistance AEC- Power rating Part No. T.C.R. temperature (70 ) tolerance range Q200 -6 (inch size) range (10 /K) (W) (%) () Grade () 10 m R < 22 m : 0 to +350 22 m R < 47 m : 0 to +200 1 47 m R < 100 m : 0 to +150 ERJC1 100 m R 1 : 100 2 10 m to 1 (E24) 55 to +155 Grade 0 (1020) 10 m R < 22 m : 0 to +350 22 m R < 100 m : 0 to +200 5 100 m R 1 : 200 *1: Use it on the condition that the case temperature is below the upper category temperature. Rated Continuous Working Voltage (RCWV) shall be determined from RCWV=Power Rating Resistance Value. Overload Test Voltage (OTV) shall be determined from OTV=Specified Magnification (refer to performance) RCW. Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use. Should a safety concern arise regarding this product, please be sure to contact us immediately. 29-Jan-20Anti-Sulfurated High Power Chip Resistors / Wide Terminal Type 70 -55 Power derating curve 100 For resistors operated in ambient temperatures 80 above 70 , power rating shall be derated in accordance with the figure on the right. 60 40 155 20 0 -60 -40 -20 0 20 40 60 80 10 120 140 160 180 Ambient temperature () Construction Protective coating Electrode (Inner) Ag-Pd-based :ERJC1B Series Alumina substrate Covered Electrode :ERJC1C Series Electrode (Between) Electrode (Outer) Thick lm resistive element Dimensions in mm (not to scale) W R01 Unit : mm Mass (Weight) Dimensions Part No. (g/1000 pcs) L W T a b ERJC1B 0.350.20 2.500.20 5.000.20 0.550.20 0.900.20 27 ERJC1C 0.600.20 Circuit Configuration R R R Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use. Should a safety concern arise regarding this product, please be sure to contact us immediately. 29-Jan-20 Rated load (%) b b a a L
