C US THIS COPY IS PROVIDED ON A RESTRICTED BASIS AND IS NOT TO BE USED IN ANY WAY DETRIMENTAL TO THE INTERESTS OF PANDUIT CORP. NOTES: DIMENSIONS - INCHES mm NUMBER EQUIVALENT 1. BRAIDED STRAP IS A TIN PLATED STRANDED COPPER WITH PART STUD AMPACITY OF BRAIDS CIRCULAR TIN PLATED SEAMLESS FERRULE ENDS. L E W T F D NUMBER HOLE (SEE NOTES) IN FERRULE MILS .50 12.7 .020 0.51 .060 1.52 .030 0.76 MINIMUM .020 0.51 2. DIMENSIONS IN BRACKETS ARE MILLIMETERS. B1S12E0084 12.00 304.8 1.030 26.16 0.140 3.56 2.500 63.50 1.250 31.75 190 84000 3. cULus LISTED (UL 467) FOR GROUNDING AND BONDING B1S24E0084 24.00 609.6 1.030 26.16 0.140 3.56 2.500 63.50 1.250 31.75 190 84000 APPLICATIONS. B1S18G0168 18.00 457.2 0.440 11.18 1.500 38.10 0.175 4.45 1.500 38.10 3/8 340 168000 B1S24G0168 24.00 609.6 1.500 38.10 0.175 4.45 1.500 38.10 340 168000 4. AMPACITY IS ONLY TO BE USED AS AN ESTIMATE. THEY ARE BASED ON 22 C FREE AIR AMBIENT AND 30 C TEMPERATURE RISE. B1S18G0303 18.00 457.2 1.500 38.10 0.255 6.48 1.500 38.10 415 303000 THE CONTINUOUS USE AMPACITY NEEDS TO BE ADJUSTED FOR B1S12N0084 12.00 304.8 1.030 26.16 0.140 3.56 190 84000 SUCH CONDITIONS AS: AMBIENT TEMPERATURE, ORIENTATION, B1S18N0084 18.00 457.2 1.030 26.16 0.140 3.56 190 84000 TEMPERATURE RISE, NUMBER OF BRAIDED STRAPS TOGETHER, AND OTHER SERVICE CONDITIONS. B1S24N0084 24.00 609.6 1.030 26.16 0.140 3.56 190 84000 B1S18N0168 1 18.00 457.2 1.500 38.10 0.175 4.45 340 168000 B1S18N0303 18.00 457.2 1.500 38.10 0.255 6.48 3.000 76.2 415 303000 B1S24N0303 24.00 609.6 1.500 38.10 0.255 6.48 415 303000 0.560 14.22 1.750 44.50 1/2 B1S12N0168 12.00 304.8 1.500 38.10 0.170 4.32 340 168000 LISTED B1S24N0168 24.00 609.6 1.500 38.10 0.170 4.32 340 168000 B1S12N0230 12.00 304.8 1.190 30.23 0.250 6.35 360 230000 B1S18N0230 18.00 457.2 1.190 30.23 0.250 6.35 360 230000 B1S24N0230 24.00 609.6 1.190 30.23 0.250 6.35 360 230000 B1S12N0303 12.00 304.8 1.500 38.10 0.250 6.35 415 303000 L E DIA REFERENCE CHART 4 PLCS FOR PART NUMBER W 2 PLCS B1S12E0084 D 2 PLCS F 2 PLCS T 2 PLCS TITLE 2 HOLE, 1 BRAID BRAIDED BONDING STRAPS CUSTOMER DRAWING ITEM REVISION NAME 00100EBA/03 REVISED CIRCULAR MIL DESCRIPTION IN TABLE 046857 03 5/19 JHNU BKR RGB DATASET FILE NAME ADDED STUD HOLE TO TABLE 00100EBA-DC/03.SLDDRW REVISED NOTE 4: 22 C FREE AIR AMBIENT WAS 30 C FREE AIR NPI-PWRGRD- MATERIAL ADDED PART NUMBERS B1S12N0084, B1S18N0084, B1S24N0084, 02 9/18 JHNU BKR RGB UNLESS OTHERWISE SPECIFIED, B1S18N0168, B1S18N0303, B1S24N0303, B1S12N0168, B1S24N0168, 039358 DIMENSIONAL TOLERANCES ARE: IN mm B1S12N0230, B1S18N0230, B1S24N0230, B1S12N0303 SEE NOTES .X .XXX 01 11/17 JHNU BKR RGB REVISED T DIMENSION AND TOLERANCE .XX ANGLES THIRD ANGLE DRAWING NUMBER 00 10/17 JHNU BKR RGB DRAWING RELEASED 00100EBA-DC PROJECTION DRAWN BY DATE CHK SCALE SIZE BY CHK APR REV DATE ECN SHEET 1 0F 1 DESCRIPTION JHNU 10/17 BKR N/A B B C US B1S12E0084X-ON Electronics Largest Supplier of Electrical and Electronic Components Click to view similar products for Cable Mounting & Accessories category: Click to view products by Panduit manufacturer: Other Similar products are found below : HP-4N 582603-1 009333-000 727844N003 809090N001 8109 843188-000 843459N001 843460N003 8666 967279N002 GPQC1/0 DB- 11 1300830208 1300840039 1300900026 1300990052 1301740005 1301800121 1301800416 1300830184 1300990149 1301580036 1301720103 1301720135 1301720152 1301720157 1301740009 1301770011 1301850553 1301860939 1302000074 1302264431 1337706-2 APA18-AK MTX6UTPSRC-C 1-787307-1 185491N001 HP-6N C-202-C 202C221-13-0 OMTM-S10-C0 205339-4 CA7308- 000 8S23-75FR-CS8184 2684 9648 3089 988382-000 A0270164
