QuickNet Fiber Cabling in the Data Center APPLICATION Your network supports the critical data, voice, video, and security applications required to drive your business . QuickNet Fiber Cabling System simplifies GUIDE the delivery of network services by providing reliable infrastructure components assembled and tested in a factory-controlled environment . An end-to-end cabling system is an ideal solution for data centers especially when time for traditional cable installation and termination is limited . QuickNet Fiber Cabling System components are terminated, tested and configured to fit the application, offering quick, plug-in deployment for trouble free network performance . With the benefits of quick network deployment, assured performance, quality, and easy redeployment, the Panduit QuickNet Fiber Cabling System is the perfect infrastructure solution for todays data centers . Quick Reference QuickNet Fiber Cabling Systems . 2 How to Use QuickNet Fiber Cabling Systems . 3 QuickNet Fiber Cable Assembly Configurations . 7 10G to 4G Migration . 8 How to Configure QuickNet Fiber Cable Assemblies 9 Reach Table . 11 Guide for Measuring QuickNet Fiber Cable Assembly Lengths 12 QuickNet Part Numbers . 14 Selecting Fiber Optic Cassettes to support your QuickNet Fiber Cabling System 20 QuickNet Fiber Accessory Part Numbers 22 www.panduit.comwww.panduit.com 1 QuickNet Fiber Cabling Systems QuickNet Fiber Cabling Systems are available in a range of configurations and met the unique needs of data center projects of any scale . This guide covers common considerations for using QuickNet Fiber Cabling Systems: Applications in the data center QuickNet Fiber Termination options and common configurations Specifying options, measuring for lengths and selecting QuickNet Fiber part numbers QuickNet Fiber Applications in the Data Center QuickNet products can be used for a wide variety of permanent link needs that are common in data center architectures such as Middle of Row (MoR) or End of Row (EoR) configurations, shown in Figure 1 . Figure 1 Data Center Applications Overhead In-Row Trunks Overhead Row-to-Row/ Pod-to-Pod Trunks Underfloor In-Row Trunks Underfloor Row-to-Row/ Pod-to-Pod Trunks Switch Port Harness 2 www.panduit.com
