IndustrialNet Category 5e Shielded 600 V-Rated Patch Cords SPECIFICATION SHEET specifications Industrial patch cords shall be constructed of Category 5e, industrial grade, IndustrialNet Category 5e Shielded 24 AWG stranded, twisted 4-pair shielded SF/UTP cable with a flame 600 V-Rated Patch Cords retardant (CM) thermoplastic elastomer (TPE) jacket. Patch cord cable shall be offered in multiple colors and lengths for design flexibility. Each patch cord CM/CMX: *ISTPHCH1MTL shall be pre-terminated to include Category 5e RJ45 shielded modular plugs IndustrialNet Category 5e SF/UTP on each end, with a black strain relief boot, and wired according to the T568A standard. Each patch cord is designed to support high-flex applications and Copper Cable is rated for 600 V panel or on-machine applications when the space is shared with high voltage power cables. CM/CMX 2-pair: ISFCH5C02A**-XG technical information 4-pair: ISFCH5C04A**-XG Electrical/ Exceeds channel and component requirements of IndustrialNet Category 6/5e RJ45 mechanical performance: ANSI/TIA-568-C.2 Category 5e and ISO 11801 Class D Field Terminable Plug standards at swept frequencies up to 100MHz meets ODVA Ethernet/IP electrical and mechanical performance requirements Field FCC and ANSI Meets all applicable ANSI/TIA-968-A requirements contacts plated with 50 terminable plug: ISPS688FA compliance: microinches of gold for superior performance IndustrialNet M12 D-Code Field IEC compliance: Meets IEC 60603-7 Terminable Plug UL-rated: UL 1863 approved Field terminable plug: ISPS5E44MFA IP compliance: Rated IP20 RoHS compliancy status: Compliant IndustrialNet M12 D-Code to RJ45 Panel Mount Adapter PoE compliance: Meets IEEE 802.3af and IEEE 802.3at for PoE applications Panel Other UL AWM Style 2463 (80C 600 V) mount adapter: ICAM12DRJS standard compliances: Flex Life Test: 1 million cycles at 10x cable diameter 10 million cycles at 20x cable diameter Mini-Com Modular Patch Panel Torsion Life Test: 3 million cycles, 360 Temperature rating: -20C to 70C (-4F to 158F) operating 8-port: CDPP8RG -40C to 70C (-40F to 158F) storage DIN Rail Adapter Wiring scheme: T568A 1-port: CADIN1IW*** Cable jacket diameter: 7.2mm (0.285 in.) nominal Flame rating: CM (UL1685) *For other lengths, change the length designation (1M) of the part number to the Packaging: 1 unit per polyethylene bag, 10 units per carton desired length (0.3M, 0.6M, 1.5M, 2M, 2.5M, 3M, 3.5M, 4M, 4.5M, 5M, 10M, 15M, or 20M) to designate color, replace TL (Teal) suffix with key features and benefits BL (Black), RD (Red), BU (Blue), GY (Gray), or YL (Yellow). For example, the part number for a Robust Allows for patch runs between automation devices in industrial environments 2-meter teal patch cord is ISTPHCH2MTL. 600V-rated construction rated for 600 V panel or on-machine applications when the space is shared with high voltage power cables plug contact plated with 50 microinches of gold **To designate color, add suffix TL (Teal) , BL (Black), RD (Red), BU (Blue), GY (Gray), 100% performance tested Confidence that each patch cord delivers specified performance or YL (Yellow). for wire map, NEXT, and ***For standard colors other than Off White, return loss replace IW in part number with BL (Black), EI (Electric Ivory), IG (International Gray), or Centered Performs in center of ANSI/TIA-568-C.2 component range, WH (White). de-embedded plug ensuring interoperability and optimum performance Integral pair manager Optimizes performance and consistency by reducing untwist at the plug Flexible stranded cable 24 AWG stranded copper cable with a nominal diameter of 7.2mm (0.285 in.) allows for high density applications and superior panel cable management Identification provides Identification of performance level, length, and quality control number for future traceability applications IndustrialNet Patch Cords provide an ideal solution to Key applications include: support Industrial Ethernet from the Local Area 10BASE-T (Ethernet) Network (LAN) based support offices to the 100BASE-T (Fast Ethernet) processing devices on the plant floor. The industrial 1000BASE-T (Gigabit Ethernet) Ethernet patch cord is a key component to an overall Industrial Ethernet industrial Ethernet application. The patch cord will be Ethernet/IP the interface that protects the integrity of the Ethernet Control Panel deployments featuring power data transfer from the switch or PLC out to the devices source voltages or up to the horizontal plant backbone. The patch cord Uplinks featuring gigabit data transmission incorporates a durable oil and UV resistant TPE from the control panel to the consolidation point jacketed cable with modular plugs and is fully shielded High flex applications Robotic, C-Track for use in high noise (EMI/RFI) environments. www.panduit.com/ia IndustrialNet Category 5e Shielded 600 V-Rated Patch Cords Conductor Insulator 4x Twisted Pair Conductor Wire Foam Tape Braid Foil Shield Jacket Cross Section View of Cable Twist Tie Identification Label Strain Relief Boot Shield Tangle-Free Latch Plug Position 1 Shielded Modular Plug WORLDWIDE SUBSIDIARIES AND SALES OFFICES PANDUIT US/CANADA PANDUIT EUROPE LTD. PANDUIT SINGAPORE PTE. LTD. PANDUIT JAPAN PANDUIT LATIN AMERICA PANDUIT AUSTRALIA PTY. LTD. Phone: 800.777.3300 London, UK Republic of Singapore Tokyo, Japan Guadalajara, Mexico Victoria, Australia Phone: 44.20.8601.7200 Phone: 65.6305.7575 Phone: 81.3.6863.6000 Phone: 52.33.3777.6000 Phone: 61.3.9794.9020 For a copy of Panduit product warranties, log on to www.panduit.com/warranty For more information 2017 Panduit Corp. Visit us at www.panduit.com/ia ALL RIGHS RESERVED. iai panduit.com COSP346--WW-ENG 3/2017
