STPCH24MBRD Panduit

2 1 THIS COPY IS PROVIDED ON A RESTRICTED BASIS AND IS NOT TO BE USED IN ANY WAY DETRIMENTAL TO THE INTERESTS OF PANDUIT CORP. NOTES: ** 1. SEE CURRENT CATALOG FOR VARIOUS APPLICATIONS AND TO TWIST TIE TO INDICATE COLOR AND/OR PACKAGE QUANTITY. 2. SEE CATALOG FOR A COMPLETE LIST OF PARTS APPLICABLE FOR USE WITH THIS PART. 3. TERMINATED WITH (8 POSITION) SHIELDED MODULAR PLUGS ON BOTH ENDS PER T568A. 4. CONSTRUCTED WITH 26AWG STRANDED CAT5e F/UTP LSZH/CM PATCH CABLE. CABLE COLOR: INTERNATIONAL GRAY 5. MATERIAL: PLUG: POLYCARBONATE SHIELD: COPPER ALLOY NICKEL PLATED BOOT: THERMOPLASTIC RESIN B B CABLE: DUAL-RATED CM/LSZH 6. NOMINAL CABLE JACKET DIAMETER IS 0.205 IN (5.21MM). STRAIN RELIEF BOOT SHIELD T568A WIRING SCHEME 5S PLUG POSITION: CABLE WIRE: IDENTIFICATION LABEL 1 WHITE/GREEN 2 GREEN 3 WHITE/ORANGE 5S TANGLE-FREE LATCH 4 BLUE 5 WHITE/BLUE 6 ORANGE 7 WHITE/BROWN SHIELDED MODULAR PLUG 8 BROWN SEE SHEET 2 FOR PATCH CORD LENGTHS AND PART NUMBERS PLUG POSITION 1 PART NUMBER STPCH MB** TITLE TX5e SHIELDED PATCH CORDS (CM/LSZH) A A CUSTOMER DRAWING ITEM REVISION NAME M01895CB/00 DATASET FILE NAME M01895CB DC07/00G MATERIAL: UNLESS OTHERWISE SPECIFIED, DIMENSIONAL TOLERANCES ARE: IN mm SEE NOTES .X .XXX Q. REMOVED BROWN COLOR FROM PRODUCT OFFERING .XX ANGLES 6 4-12-16 BJN MDJR SASK P. UPDATED TITLE BLOCK 01895-07 DRAWING NUMBER: THIRD ANGLE REVISED & REDRAWN PREVIOUS REVISIONS REMVD FOR CLARITY PROJECTION 01895-07 P DRAWN BY DATE CHK SCALE SIZE REV DATE BY CHK APR DESCRIPTION ECN BJN 6-4-06 EJH NONE SHT 1 OF 1 A 2 1 D10100DA/142 1 THIS COPY IS PROVIDED ON A RESTRICTED BASIS AND IS NOT TO BE USED IN ANY WAY DETRIMENTAL TO THE INTERESTS OF PANDUIT CORP. TX5e SHIELDED PATCH CORDS PART NUMBER LENGTH(MIN) ft(m) STPCH0.5MB** 1.64ft (0.5m) STPCH1MB** 3.28ft (1m) STPCH1.5MB** 4.92ft (1.5m) JACKET STPCH2MB** 6.56ft (2m) STPCH2.5MB** 8.20ft (2.5m) STPCH3MB** 9.84ft (3m) CONDUCTOR INSULATION B B STPCH4MB** 13.12ft (4m) CONDUCTOR WIRE STPCH5MB** 16.40ft (5m) STPCH6MB** 19.68ft (6m) DRAIN WIRE STPCH7MB** 22.97ft (7m) STPCH8MB** 26.25ft (8m) STPCH9MB** 29.53ft (9m) STPCH10MB** 32.80ft (10m) STPCH15MB** 49.21ft (15m) STPCH20MB** 65.62ft (20m) FOIL 4X TWISTED PAIR STPCH25MB** 82.02ft (25m) TAPE STPCH30MB** 98.42ft (30m) STPCH35MB** 114.83ft (35m) STPCH40MB** 131.23ft (40m) CROSS-SECTIONAL VIEW OF CABLE BOOT COLORS ** = COLOR BLACK BL BLUE BU PART NUMBER RED RD STPCH MB** YELLOW YL TITLE GREEN GR TX5e SHIELDED PATCH CORDS (CM/LSZH) A A Q CUSTOMER DRAWING ITEM REVISION NAME M01895CB/00 DATASET FILE NAME M01895CB DC07/00G MATERIAL: UNLESS OTHERWISE SPECIFIED, DIMENSIONAL TOLERANCES ARE: IN mm SEE NOTES .X .XXX .XX ANGLES DRAWING NUMBER: THIRD ANGLE 6 4-12-16 BJN MDJR SASK SEE SHEET 1 FOR REVISION HISTORY 01895-07 PROJECTION 01895-07 DRAWN BY DATE CHK SCALE SIZE REV DATE BY CHK APR DESCRIPTION ECN BJN 6-4-06 EJH NONE SHT 2 OF 2 A 2 1 D10100DA/14
