Screened FTP Cat 7A LSZH Cable 1,200MHz Application: Horizontal Wiring in LAN Multi-Construction : 4 Pair Cable Construction Conductor : Solid Bare Copper 2 Conductor Area CSA : 0.32mm Wire Size AWG : 22 Construction : 0.62 0.01 Standard Dia.(mm) : 0.62 Insulation : Skin - Foam - Skin Average Thickness : 0.4 Insulation Dia.(mm) : 1.45 0.1 2C Twist Al-Pet shield(on each pair, Al outward) : 115% Braiding Shield : Tin-Plated Copper Wire Construction : 0.12 0.003 8 6 Jacket Jacket Material : Low Smoke Zero Halogen (LSZH) Flame Retardant Polyethylene Thickness(mm) : 0.7 Dia.(mm) : 8.2 0.3 Jacket Colour : Yellow Colour Insulation colour are : Blue, White/Blue Orange,White/Orange Green, White/Green Brown, White/Brown Characteristics Max. Conductor DC Resistance at 20C (/Km) : <66.6 Rated Temperature(C) : 70 Velocity ratio : 78% 1-100MHz 100 15 Impedance() : 100-250MHz 100 20 250-500MHz 100 25 500-1,000MHz 100 30 1,000-1,200MHz 100 32 www.element14.com www.farnell.com www.newark.com www.cpc.co.uk Page <1> 30/09/14 V1.1Screened FTP Cat 7A LSZH Cable 1,200MHz Performance: Frequency Attenuation NEXT PS NEXT Return loss ELFEXT PSELFEXT (MHz) (dB) (dB) (dB) (dB) (dB) (dB) 1 2.1 78 75 20 78 75 4 3.7 78 75 23 78 75 10 5.8 78 75 25 75.3 72.3 16 7.3 78 75 25 71.2 68.2 31.25 10.3 78 75 23.6 65.4 62.4 62.5 14.6 78 75 21.5 59.4 56.4 100 18.5 75.4 72.4 20.1 55.3 52.3 250 29.7 69.4 66.4 17.3 47.3 44.3 500 42.8 64.9 61.9 17.3 41.3 38.3 600 47.1 63.7 60.7 17.3 39.7 36.7 900 58.5 61.1 58.1 15.5 36.2 33.2 1,000 61.9 60.4 57.4 15.1 35.3 32.3 1,200 68.4 59.2 56.2 14.3 33.7 30.7 Design: Part Number Table Description Part Number Cable, MULTIPR, 4PR, CAT 7A, LSZH, YEL, 100m PP000426 Cable, MULTIPR, 4PR, CAT 7A, LSZH, YEL, 500m PP000427 Important Notice : This data sheet and its contents (the Information) belong to the members of the Premier Farnell group of companies (the Group) or are licensed to it. No licence is granted for the use of it other than for information purposes in connection with the products to which it relates. No licence of any intellectual property rights is granted. The Information is subject to change without notice and replaces all data sheets previously supplied. The Information supplied is believed to be accurate but the Group assumes no responsibility for its accuracy or completeness, any error in or omission from it or for any use made of it. Users of this data sheet should check for themselves the Information and the suitability of the products for their purpose and not make any assumptions based on information included or omitted. Liability for loss or damage resulting from any reliance on the Information or use of it (including liability resulting from negligence or where the Group was aware of the possibility of such loss or damage arising) is excluded. This will not operate to limit or restrict the Groups liability for death or personal injury resulting from its negligence. pro - POWER is the registered trademark of the Group. Premier Farnell plc 2012. www.element14.com www.farnell.com www.newark.com www.cpc.co.uk Page <2> 30/09/14 V1.1
