CY LSZH / BS EN 50525-3-11 Multiconductor Screened Flexible Control Cable Application: For installation where fire, smoke emission and toxic fumes create a potential threat to life and equipment. Used as interconnecting cable for measuring, controlling or regulation in control equipment for assembly and production lines, conveyors and for computer units. Suitable for fixed installations or for flexible use when temporarily moved, and in conditions of medium mechanical stress. Can be used outdoors when protected, and in dry or damp conditions indoors. Construction: Conductor: Class 5 flexible copper conductor according to BS EN 60228 (previously BS 6360) Insulation: Halogen Free Type TI6 according to BS EN 50363 Binding Tape: PET (Polyester Tape) Screen: TCWB (Tinned Copper Wire Braid) Sheath: LSZH (Low Smoke Zero Halogen) Type TM7 according to BS EN 50363-8 Cable Standards Generally to BS EN 50525-3-11, BS EN/IEC 60754-1, BS EN/IEC 60332-1-2 Characteristics: Voltage Rating (Uo/U) 300/500V Temperature Rating: Installation : -15C to +70C Operating : -30C to +70C Minimum Bending Radius: Fixed : 6 overall diameter Flexed : 15 overall diameter www.element14.com www.farnell.com www.newark.com www.cpc.co.uk Page <1> 10/02/15 V1.3CY LSZH / BS EN 50525-3-11 Multiconductor Screened Flexible Control Cable Core Identification: Number Coded Cores Black with White numbers 3 cores and above to include Green/Yellow Colour Coded Cores: 3 core : Green/Yellow, Brown, Blue 4 core : Green/Yellow, Brown, Black, Grey Sheath Colour: Grey Dimensions: Nominal Cross Nominal Overall No. of Nominal Weight Part Number Sectional Area Diameter Cores Kg/Km mm mm PP000488 0.75 6.1 45 PP000489 2 1 6.3 57 PP000490 1.5 7.3 75 PP000491 0.75 6.4 63 PP000492 3 1 6.6 73 PP000493 1.5 7.7 95 PP000494 0.75 6.9 89 PP000495 4 1 7.1 86 PP000496 1.5 8.4 118 Conductors: Class 5 Flexible Copper Conductors for Single Core and Multi-Core Cables Nominal Cross Sectional Area Maximum Resistance of Conductor at 20C mm 0.75 26 1 19.5 1.5 13.3 www.element14.com www.farnell.com www.newark.com www.cpc.co.uk Page <2> 10/02/15 V1.3
