Flexible Screened Bedded LSZH Multicore Cable Application Pro-Power halogen-free flexible screened connecting cables for use in mechanical engineering for instrumentation and control equipment and for tooling machinery production lines. Suitable for flexible applications for free movement without tensile load, in dry, moist and wet rooms. The screen protects against external interference pulses and whilst the bedding provides additional mechanical protection. These cables are not used for outdoor or underground installation. Characteristics Voltage Rating : 300/500V Test Voltage : 2kV Temperature Rating : Fixed: -40C to +80C Flexed: -15C to +70C Minimum Bending Radius : Fixed: 6 overall diameter Moved: 15 overall diameter Cable Standards VDE 0295, VDE 0207-303-7, VDE 0293-308, VDE 0285-525-2-51, VDE 0285-525-3-11, VDE 0482-332-1-2, VDE 0819-102 Flame Retardant according to IEC 60332-3-24, IEC 60332-1-2 Low Smoke Density / Halogen free according to IEC 61034-2, IEC 60754-1/2 UK Laboratory Tested This product is subject to the Quality Assurance protocols of The Cable Lab, a UKAS accredited ISO 17025 cable testing laboratory. Testing includes vertical flame, conductor resistance, tensile & elongation, and dimensional consistency, verified to published standards and approved product drawings. Regulatory Compliance This cable meets the requirements of the Low Voltage Directive 2014/35/EU and the RoHS Directive 2011/65/EU. RoHS compliance has been tested and confirmed by The Cable Lab as meeting the requirements of the BSI RoHS Trusted TM Kitemark . Construction Conductor Class 5 flexible plain copper wires Insulation LSZH (Low Smoke Zero Halogen) www.element14.com www.farnell.com www.newark.com www.cpc.co.uk Page <1> 09/02/18 V1.2Flexible Screened Bedded LSZH Multicore Cable Bedding LSZH (Low Smoke Zero Halogen) Screen TCWB (Tinned Copper Wire Braid) Sheath LSZH (Low Smoke Zero Halogen) Core Identification Black with white number From 3 cores: Black with white number + Green/Yellow Sheath Colour Grey Dimensions Nominal Cross Nominal Thickness Nominal Thickness Nominal Overall Nominal No. of Part Number Sectional Area of Insulation of Sheath Diameter Weight Cores mm mm mm mm kg/km PP001530 2 0.5 0.4 0.8 6.8 77 PP001531 3 1.5 0.4 1 9 152 PP001532 3 2.5 0.5 1.1 11.1 243 PP001533 5 1.5 0.4 1.1 10.5 208 PP001534 5 4 0.6 1.3 14.9 463 PP001535 7 1.5 0.4 1.1 11.2 251 PP001536 7 4 0.6 1.4 16.2 588 PP001537 12 1.5 0.4 1.4 14.8 414 PP001538 18 1.5 0.4 1.5 17 569 Electrical Characteristics Nominal Cross Current Carrying Capacities 30C Maximum Resistance Sectional Area Continuous Loading of Conductor at 20C mm A /km 0.5 9 39 1.5 18 13.3 2.5 26 7.98 4 34 4.95 www.element14.com www.farnell.com www.newark.com www.cpc.co.uk Page <2> 09/02/18 V1.2
