TSI-S22-1100-NAT Pro Power

Standard Wall PTFE Insulating Tubing Description TSI (AWG) series is a standard wall, chemically inert tubing which offers superior insulating properties. It features excellent flex life, heat resistance and is self extinguishing. Applications Electrical Insulation Protective Cover Circuit Board Wire Insulation Strain Relief Introducer Stent Delivery Features Virgin Polytetrafluoroethylene resin Chemically inert Lowest coefficient of friction Superior dielectric strength Exceptional heat resistance Self extinguishing Non-wetting Excellent flexlife Laser markable Specifications Material : PTFE Colour : Natural Working Temperature : 260C (500F) Flammability : UL83 (natural) Certifications/Compliance ASTM D3295 Class 3 AMS 3653E MIL-I-22129C UL-224 600V 200C CSA 9032-01 600V VW1, UL-83 (natural) FDA Compliant USP Class VI Compliant www.element14.com www.farnell.com www.newark.com www.cpc.co.uk Page <1> 10/11/17 V1.1Standard Wall PTFE Insulating Tubing Diagram PTFE TSI (AWG) Series Standard Wall Inside Diameter Wall Thickness AWG Nominal Minimum Maximum Nominal Part Number Size I.D. I.D. I.D. Wall Inch mm Inch mm Inch mm Inch mm TSI-S24-1100-NAT 24 0.022 0.56 0.02 0.51 0.026 0.66 0.012 0.003 0.31 0.08 TSI-S22-1100-NAT 22 0.028 0.71 0.025 0.64 0.032 0.81 0.012 0.003 0.31 0.08 TSI-S20-1100-NAT 20 0.034 0.86 0.032 0.81 0.04 1.02 0.016 0.003 0.41 0.08 TSI-S18-1100-NAT 18 0.042 1.07 0.04 1.02 0.049 1.25 0.016 0.003 0.41 0.08 TSI-S16-1100-NAT 16 0.053 1.35 0.051 1.3 0.061 1.55 0.016 0.003 0.41 0.08 TSI-S14-1100-NAT 14 0.066 1.68 0.064 1.63 0.074 1.88 0.016 0.003 0.41 0.08 TSI-S12-1100-NAT 12 0.085 2.16 0.081 2.06 0.091 2.31 0.016 0.003 0.41 0.08 TSI-S10-1100-NAT 10 0.106 2.69 0.102 2.59 0.112 2.84 0.016 0.003 0.41 0.08 TSI-S08-1100-NAT 8 0.133 3.38 0.129 3.28 0.141 3.58 0.02 0.004 0.51 0.1 TSI-S06-1100-NAT 6 0.166 4.22 0.162 4.11 0.178 4.52 0.02 0.004 0.51 0.1 TSI-S05-1100-NAT 5 0.185 4.7 0.182 4.62 0.196 4.98 0.02 0.004 0.51 0.1 TSI-S04-1100-NAT 4 0.208 5.28 0.204 5.18 0.224 5.69 0.02 0.004 0.51 0.1 Part Number Table Description Packaging Part Number Description Packaging Part Number TSI-S24-1100-NAT TSI-S12-1100-NAT TSI-S22-1100-NAT TSI-S10-1100-NAT TSI-S20-1100-NAT TSI-S08-1100-NAT Standard Wall PTFE 100ft Standard Wall PTFE 100ft Insulating Tubing (30.5m) Insulating Tubing (30.5m) TSI-S18-1100-NAT TSI-S06-1100-NAT TSI-S16-1100-NAT TSI-S05-1100-NAT TSI-S14-1100-NAT TSI-S04-1100-NAT Important Notice : This data sheet and its contents (the Information) belong to the members of the Premier Farnell group of companies (the Group) or are licensed to it. No licence is granted for the use of it other than for information purposes in connection with the products to which it relates. No licence of any intellectual property rights is granted. The Information is subject to change without notice and replaces all data sheets previously supplied. The Information supplied is believed to be accurate but the Group assumes no responsibility for its accuracy or completeness, any error in or omission from it or for any use made of it. Users of this data sheet should check for themselves the Information and the suitability of the products for their purpose and not make any assumptions based on information included or omitted. Liability for loss or damage resulting from any reliance on the Information or use of it (including liability resulting from negligence or where the Group was aware of the possibility of such loss or damage arising) is excluded. This will not operate to limit or restrict the Groups liability for death or personal injury resulting from its negligence. pro - POWER is the registered trademark of the Group. Premier Farnell Limited 2016. www.element14.com www.farnell.com www.newark.com www.cpc.co.uk Page <2> 10/11/17 V1.1
