NMOKHFCXTHK Pulse

Roof Mount NMOHFGPS / Pulse Part Number NMOHFGPS Family Pulse/Larsens line of NMO mount antennas include low band all the way to 5.9 GHz. These antennas are designed for use in public safety, search and rescue, trucking, commercial fleets, GIS, and survey/mapping markets. Multiband designs are ideal for applications requiring GPS tracking and data transmission. With the new NMOHFGPS series, Pulse/Larsen has com- bined the high performance of a GPS antenna with the flexibility of adding an NMO high frequency mount on the top for easy combination with virtually any Pulse/Larsen NMO mount antenna from 27 MHz to 6.0 GHz. Simply pull the center pin and insulator to convert from low fre- quency to high frequency applications. Pulling the cen- ter pin creates a coax-type connection optimal for high frequency applications. The larger center contact pin provides additional strength against downward compres- sion during low frequency installations, resulting in better Low Frequency VSWR. Features - Easily Converts from Low to High Frequency Use - Large Center Contact Pin for Better VSWR - Combines NMOHF Mount with a GPS LNA Module - RoHS Compliant Product Applications - Public Safety, Search and Rescue - AVL (Automatic Vehicle Location) - Survey/Mapping Part Number Connector NMOHFGPSNOCONN No Connectors FME Female / NMOHFGPSFMENOCONN No Connector (GPS) FME Female / NMOHFGPSFMESMA SMA Male (GPS) SMA Male / NMOHFGPSSMASMA SMA Male (GPS) San Diego, CA 858 674 8100 Vancouver, WA 360 944 7551 Europe 49 7032 7806 0 Asia 86 755 33966678 North Asia 886 3 4356768 China 86 512 6807 9998 1 pulseelectronics.com/products/antennas L125.A (05/11)Roof Mount NMOHFGPS Pulse Part Number NMOHFGPS Family Electrical Specifications - Mount Only GPS Specifications Nominal Impedance [] 50 Frequency [MHz] 1574.4-1576.4 Output VSWR 2.0:1 5V Gain [dBic / dB 2] 5 / 26 Right Hand Current Draw [mA Max] 25 Polarization Circular Voltage [V DC] 3 - 5 DC Resistance [k] 5 Type [NMOHF] RG-58 Type [GPS] RG-174 Length - NMOHF [Feet/ Meters] 17 / 5.18 Environmental Specifications Length - GPS [Feet/Meters] 17 / 5.18 Operating Temperature [C] -40 to +85 Storage Temperature [C] -40 to +85 Mechanical Specifications Makroblend (UV Side Profile Illustration Radome Material Stable) NMOHFGPS Color Black Ingress Protection IP-65 Wind-loading [mph] 150 Through Bolt 2 x 1.5 x 0.7 / 50.8 x Dimensions [Inches/mm] 338.1 x 17.78 Direct feed, 3/4 Cables Mounting threaded through hole [see illustration] 22 pulseelectrpulseelectronics.onics.ccom/om/prproducts/oducts/antantennasennas L125.A (05/11) Cable
