Quick Start Guide R12QS0042ED0203 R-IN32M3 Module (RY9012A0) Rev.2.03 Jan 29, 2021 Industrial Ethernet Module Solution Outline This document describes the start-up procedure of R-IN32M3 Module starter kit that includes the R-IN32M3 TM Module. The R-IN32M3 Module starter kit with the application controller Synergy S7G2 development environment, SK-S7G2, takes care of the complex handling of several industrial Ethernet protocols (such as TM PROFINET, EtherNet/IP and EtherCAT ). Example software of the SK-S7G2 is provided as source code and can thus be ported to other development platforms such as for RX MCUs. Accordingly, this R-IN32M3 Module starter kit allows the quick development of software prototypes of the industrial network communications and applications. The software package that comes with the R-IN32M3 Module starter kit includes not only an integrated software development environment and example software but includes a Management Tool (Industrial Communication Explorer) from the companyport industrial automation Gmb) which has the protocol master function of PROFINET, EtherNet/IP and EtherCAT and can configure and monitor the R-IN32M3 Module. The R-IN32M3 Module starter kit enables the user to quickly become familiar with the industrial Ethernet protocols (such as PROFINET, EtherNet/IP or EtherCAT) by use of the example applications and to quickly develop applications on the industry-standard arm microcontroller of the Renesas Synergy SK-S7G2 starter kit. R12QS0042ED0203 Page 1 of 31 Jan 29, 2021 R-IN32M3 Module Quick Start Guide 1. R-IN32M3 Module Starter Kit 1.1 System Requirements The R-IN32M3 Module starter kit requires the following environment for the evaluation. Renesas Synergy SK-S7G2 starter kit rev. 3.3 or a later version PC OS: Windows 7/8/10 Memory: At least 8 GB LAN ports USB 2.0 ports R12QS0042ED0203 Page 2 of 31 Jan 29, 2021
