3CRH30330 ROXBURGH EMC

SPARK QUENCHERS 500 VAC Fax Back Document 1206 Safety Agency : Standard File No. CRH SERIES UL : UL1283 E78644 O 500 VAC rating for application in high voltage phase control 3CRH SERIES O Flexible wire leads with external O 500VAC rating for application in mounting tab high voltage three phase control O 6 and 10 watt non-inductive, high O Flexible wire leads and external mounting tab pulse resistors O 6 and 10 watt non-inductive, high pulse resistors ELECTRICAL SPECIFICATIONS Operating temp. range : -40 ~ + 70C Pulse condition (Max) Capacitance Peak Test Peak Safety Resistance Insulation Pulse width (sec) Model No. Cx pulse voltage to Pulse Repetitive h Standard 30% resistance x (F20%) voltage JISC5102 Peak width frequency Frequency(Hz) (P-P) Line to Line to Line CRH-10680 0.1 68(6W) 50msec.max 1.0max Line h 10,000M 1250Vrms min. 50/60Hz CRH-20470 0.22 47(6W) 70msec.max 0.3max 60sec. 1000V 720Hz. 1500V Line to CRH-30330 0.33 33(6W) 100msec.max 0.2max Case max max max Line to h 10,000M CRH-50270 0.47 27(10W) 100msec.max 0.2max Case min. 2000Vrms 3CRH-30330 0.33/1phase 33(6W)/1phase 100msec.max 0.2max 50/60Hz (at 20C 60sec. 3CRH-50270 0.47/1phase 27(10W)/1phase 100msec.max 0.2max 500 VDC) 2-22MECHANICAL SPECIFICATIONS: Case Material: Polybutylene Terephthalate (FR-PBT) UL-94 Flame Class V-O Potting Material: UL-94 Flame Class V-O Leads: Tinned Stranded Copper Wire Polyvinylchloride (PVC) Insulation Soldered Capacitor Element Capacitor: Double Wound, Oil Impregnated, Metallized Polyester Film CRH 3CRH All Dimensions in MM MECHANICAL DIMENSIONS Other lead lengths availableconsult factory. Dimensions Safety Capacitance Resistance Model No. h Standard (F20%) 30% L H T F CRH-10680 0.1 68(6W) 15.0 CRH-20470 0.22 47(6W) 30.0 18.0 57.0 CRH-30330 0.33 33(6W) 20.0 CRH-50270 0.47 27(10W) 40.0 28.0 3CRH-30330 0.33/1phase 33(6W)1 phase 46.0 32.0 13.0 62.0 3CRH-50270 0.47/1phase 27(10W)1 phase 56.0 40.0 18.0 2-23 SPARK QUENCHERS
