Si5347-D-EVB Si5347-D EVALUATION BOARD USERS GUIDE Description EVB Features The Si5347-D-EVB is used for evaluating the Si5347 Powered from USB port or external +5 V power Any-Frequency, Any-Output, Jitter-Attenuating Clock supply via screw terminals. Multiplier revision D. The device revision is Onboard 48 MHz XTAL allows standalone or distinguished by a white 1 inch x 0.187 inch label with holdover mode of operation on the Si5347. the text SI5347-D-EB installed in the lower left hand CBPro GUI programmable V supply allows DD corner of the board. (For ordering purposes only, the device supply voltages of 3.3, 2.5, or 1.8 V. terms EB and EVB refer to the board and the kit CBPro GUI programmable V supplies allow each DDO respectively. For the purpose of this document, the of the 8 outputs to have its own supply voltage terms are synonymous in context.) selectable from 3.3, 2.5, or 1.8 V. CBPro GUI allows control and measurement of voltage, current, and power of V and all 8 V DD DDO supplies. Status LEDs for power supplies and control/status signals of Si5347. SMA connectors for input clocks, output clocks and optional external timing reference clock. Figure 1. Si5347-D Evaluation Board Rev. 0.9 7/16 Copyright 2016 by Silicon Labs Si5347-D-EVB Si5347-D-EVB 1. Si5347-D-EVB Functional Block Diagram Below is a functional block diagram of the Si5347-D-EB. This evaluation board can be connected to a PC via the main USB connector for programming, control, and monitoring. See section 3. Quick Start for more information. Main USB Power only +5V USB Connector Aux USB Power only +5V Aux Connector Power Supply Ext +5V +5V Ext Connector VDDMCU I2C/SPI Bus I2C/SPI Bus DSPLL SEL1 DSPLL SEL0 C8051F380 OE 0 OE 0 CLKOUT 0 Output MCU Output Clock 0 FINC Termination CLKOUT 0B + FDEC CLKOUT 1 Output Peripherals INTR Output Clock 1 Termination CLKOUT 1B Alarm Status Output CLKOUT 2 Output Clock 2 Termination CLKOUT 2B CLKOUT 3 Output XA Output Clock 3 Optional External XAXB Termination CLKOUT 3B Si5347 XAXB Ref Input Crystal / Term XB CLKOUT 4 Output Output Clock 4 Termination CLKOUT 4B Input CLKIN 0 Input Clock 0 Termination CLKIN 0B CLKOUT 5 Output Output Clock 5 Termination CLKIN 1 CLKOUT 5B Input Input Clock 1 Termination CLKIN 1B Output CLKOUT 6 Output Clock 6 Termination CLKIN 2 CLKOUT 6B Input Input Clock 2 Termination CLKIN 2B CLKOUT 7 Output Output Clock 7 Termination CLKIN 3 CLKOUT 7B Input Input Clock 3 Termination CLKIN 3B Figure 2. Si5347-D-EB Functional Block Diagram 2 Rev. 0.9 VDD Core VDD Core VDD 3.3 VDD 3.3 VDDO 0 VDDO 0 VDDO 1 VDDO 1 VDDO 2 VDDO 2 VDDO 3 VDDO 3 VDDO 4 VDDO 4 VDDO 5 VDDO 5 VDDO 6 VDDO 6 VDDO 7 VDDO 7
