RMCF1206FT13R7 Stackpole

RMC F/RMCP Series Stackpole Electronics, Inc. General Purpose Thick Film Standard Power Resistive Product Solutions and High-Power Chip Resistor RMCF standard power ratings Features: RMCP high power ratings Nickel barrier terminations standard Power derating from 100% at 70C to zero at +155C AEC-Q200 Compliant (except RMCP0201) RoHS compliant and halogen-free Electrical Specifications - RMCF Maximum Maximum Maximum Resistance (2) Power Rating Ohmic Range () and Tolerance Working Type / Code Overload Current T emperature (Watts) @ 70C (1) Voltage Voltage (Amp) Coefficient 1% 5% 1 - 9.76 -200/+600 ppm/C RMCF01005 0.03W 15V 30V 0.5 A 10 - 1M 250 ppm/C 1 - 9.76 400 ppm/C RMCF0201 0.05W 25V 50V 0.5 A 200 ppm/C 10 - 10M (4) 200 ppm/C 1 - 9.76 RMCF0402 0.063W 50V 100V 1 A 10 - 1M 100 ppm/C 200 ppm/C 1.02M - 10M 1.1M - 20M 0.1 - 0.499 500 ppm/C 0.5 - 0.976 400 ppm/C RMCF0603 0.1W 75V 150V 1 A 1 - 9.76 1 - 20M 200 ppm/C 10 - 1M - 100 ppm/C 200 ppm/C 1.02M - 10M - 0.1 - 9.76 0.1 - 20M 200 ppm/C RMCF0805 0.125W 150V 300V 2 A 10 - 1M - 100 ppm/C 200 ppm/C 1.02M - 10M - 0.1 - 9.76 0.1 - 20M 200 ppm/C RMCF1206 0.25W 200V 400V 2 A 10 - 1M - 100 ppm/C 200 ppm/C 1.02M - 10M - 0.1 - 0.976 200 ppm/C 1 - 9.76 400 ppm/C (3) RMCF1210 200V 400V 3 A 0.33W - 10 - 20M 200 ppm/C 100 ppm/C 10 - 10M - 0.1 - 0.976 200 ppm/C 1 - 9.76 400 ppm/C RMCF2010 0.75W 200V 400V 3 A - 10 - 10M 200 ppm/C 10 - 10M - 100 ppm/C 0.1 - 0.976 200 ppm/C 1 - 9.76 400 ppm/C RMCF2512 1W 200V 400V 3 A - 10 - 10M 200 ppm/C 10 - 10M - 100 ppm/C (1) Lesser of P*R or maximum working voltage Notes: (2) Contact factory for extended ohmic values (3) Power rating is 0.5W for ohmic values 1K and below (4) Contact factory for lower ohmic values Rev Date: 01/07/2019 1 www.seielect.com This specification may be changed at any time without prior notice marketing@seielect.com Please confirm technical specifications before you order and/or use. RMC F/RMCP Series Stackpole Electronics, Inc. General Purpose Thick Film Standard Power Resistive Product Solutions and High-Power Chip Resistor Electrical Specifications - RMCP Maximum Maximum Resistance (2) Power Rating Maximum Ohmic Range () and Tolerance Working Type / Code Overload Temperature (Watts) @ 70C Current (1) Voltage Coefficient Voltage 1%, 5% 1 - 9.76 -200/+400 ppm/C RMCP0201 0.063W 25V 50V 1 Amp 200 ppm/C 10 - 1M 1 - 9.76 200 ppm/C RMCP0402 0.125W 50V 100V 1.5 Amp 10 - 1M 100 ppm/C 200 ppm/C 1 - 9.76 RMCP0603 0.25W 75V 150V 2 Amp 10 - 1M 100 ppm/C 1 - 9.76 200 ppm/C RMCP0805 0.33W 150V 300V 2.5 Amp 100 ppm/C 10 - 1M 1 - 9.76 200 ppm/C RMCP1206 0.33W 200V 400V 3.5 Amp 10 - 1M 100 ppm/C 200 ppm/C 1 - 9.76 RMCP1210 0.5W 200V 400V 5 Amp 10 - 1M 100 ppm/C 200 ppm/C 1 - 9.76 RMCP2010 1W 200V 400V 6 Amp 100 ppm/C 10 - 1M 1 - 9.76 200 ppm/C RMCP2512 2W 250V 500V 7 Amp 100 ppm/C 10 - 1M Notes: (1) Lesser of P*R or maximum working voltage (2) Contact factory for extended ohmic values Mechanical Specifications L W H a b Average Unit Type / Code Unit Weight (mg) Body Length Body Width Body Height Top Termination Bottom Termination 0.016 0.0008 0.008 0.0008 0.005 0.0008 0.004 0.0012 0.004 0.0012 inches RMCF01005 0.07 0.40 0.02 0.20 0.02 0.13 0.02 0.10 0.03 0.10 0.03 mm RMCF0201 0.024 0.0012 0.012 0.0012 0.009 0.0012 0.006 0.002 0.006 0.002 inches 0.16 RMCP0201 0.60 0.03 0.30 0.03 0.23 0.03 0.15 0.05 0.15 0.05 mm RMCF0402 0.57 0.039 0.004 0.020 0.002 0.012 0.002 0.008 0.004 0.010 0.006 inches RMCP0402 0.62 1.00 0.10 0.50 0.05 0.30 0.05 0.20 0.10 0.25 0.15 mm RMCF0603 1.88 0.061 0.006 0.031 0.006 0.018 0.004 0.012 0.008 0.012 0.008 inches RMCP0603 2.04 1.55 0.15 0.80 0.15 0.45 0.10 0.30 0.20 0.30 0.20 mm RMCF0805 5.00 0.079 0.008 0.049 0.004 0.020 0.006 0.014 0.010 0.014 0.010 inches RMCP0805 4.37 2.00 0.20 1.25 0.10 0.50 0.15 0.35 0.25 0.35 0.25 mm RMCF1206 8.86 0.126 0.010 0.063 0.006 0.022 0.006 0.020 0.012 0.020 0.012 inches RMCP1206 8.95 3.20 0.25 1.60 0.15 0.55 0.15 0.50 0.30 0.50 0.30 mm RMCF1210 15.55 0.126 0.010 0.098 0.010 0.022 0.006 0.020 0.012 0.020 0.012 inches RMCP1210 15.96 3.20 0.25 2.50 0.25 0.55 0.15 0.50 0.30 0.50 0.30 mm RMCF2010 23.56 0.197 0.008 0.098 0.008 0.022 0.006 0.024 0.012 0.024 0.014 inches RMCP2010 24.24 5.00 0.20 2.50 0.20 0.55 0.15 0.60 0.30 0.60 0.35 mm RMCF2512 40.02 0.248 0.008 0.126 0.010 0.022 0.006 0.024 0.012 0.024 0.014 inches RMCP2512 39.45 6.30 0.20 3.20 0.25 0.55 0.15 0.60 0.30 0.60 0.35 mm Rev Date: 01/07/2019 2 www.seielect.com This specification may be changed at any time without prior notice marketing@seielect.com Please confirm technical specifications before you order and/or use.
