EZA2500 Series Immunity Test Standard Test Level Criteria ESD EN61000-4-2 4kV contact, 8kV discharge A Radiated Susceptibility EN61000-4-3 3V/m A Electrical Fast Transient Burst EN61000-4-4 2kV A Surge EN61000-4-5 Common 2kV, Normal 1kV A Conducted Susceptibility EN61000-4-6 3V A Magnetic elds EN61000-4-8 - A Speci cations Model EZA2500 Output Low Voltage DC (Battery Side) High Voltage DC (Grid Side) Output Voltage Adjustment See model selector Line Regulation V 0.24 1.52 Load Regulation V 0.48 3.04 Temperature Regulation (Maximum) V 0.3 1.9 Ripple & Noise V <0.48 <3.2 Sink Current (When applied V > output set V) mA 300 50 Overcurrent Protection (Manual reset) A 60 9.5 Overpower Protection (Constant Power) W 2600 2600 Under & Overvoltage Protection (1) V 32 - 68 (EZA2500W 32 - 70) 260 - 425 (EZA2500W 240 - 410) Overtemperature Protection - Alarm signal is given Remote On/Off & Reset (1) - Yes Front panel Indicators and Settings - Operating mode (Generating, Regenerating & Alarm), Alarm clear & RS-485 address selection RS-485 Functions Voltage Setting Accuracy - < 0.6V < 4V Current Setting Accuracy - < 0.8A < 0.125A Voltage Setting Resolution - < 60mV < 0.4V Current Setting Resolution - < 50mA < 8mA Voltage Reading Accuracy - < 0.6V < 4V Current Reading Accuracy - < 0.8A < 0.125A Voltage Reading Resolution - < 60mV < 0.4V Current Reading Resolution - < 50mA < 8mA RS-485 Baud Rate - 19.2kbps / 33.6kbps / 57.6kbps (Set by DIP Switch) RS-485 Maximum Connection - 14 Environmental Operating Temperature C -10 to +40C (EZA2500W -10 to +50C), see derating curve section Storage Temperature C -20 to +85C Operating Humidity (Non Condensing) %RH 30 - 95%RH (Operating & Storage) Storage Humidity (Non Condensing) %RH 10 - 95%RH (Operating & Storage) Cooling - Internal fans Altitude m 2,000m Withstand Voltage (For 1 minute) VAC Input (HVDC) to Output (LVDC) 3kVAC, Input to Ground 2kVAC, Output to Ground 500VAC Isolation Resistance M >100M at 25C & 70%RH, Output to Ground 500VDC 2 Vibration (Non-operating) - 10-500Hz (1 min sweep), 10.2m/s constant for 1 hour in each direction: X, Y & Z axis 2 Shock - 196.1m/s maximum Other Weight (Typ) g 8000 Size (WxHxD) mm 422.8 x 43.6 x 400 Size (WxHxD) Inches 16.65 x 1.72 x 15.75 Warranty yrs 5 Notes See website for detailed speci cations, test methods and installation manual (1) Can be set via RS-485 2 EZA2500 Series
