te.com DC-EC SERIES General purpose DC LVDT SPECIFICATIONS High level 10VDC output Stroke ranges from 0.05 to 10in 0.25% linearity Reverse polarity protection Double magnetic shielding Stainless steel housing Imperial or metric threaded core The DC-EC Series DC operated LVDTs combine a computer-designed AC LVDT with custom integral signal conditioning to achieve premium Features performance. Operating on a nominal 15VDC supply, the DC-EC Bi-polar DC operation Series delivers an extremely linear, low noise, yet high frequency Shock and vibration tolerant response 10VDC output. Captive core option (available on Innovative design and manufacturing techniques further enhance the select models) DC-EC performance and cost efficiency. The micro-miniature AISI 400 Series stainless steel components employed were meticulously selected for maximum stability housing and thermal performance. Vacuum encapsulation of all elements affords CE compliant excellent shock and vibration tolerance, while double magnetic shielding Calibration certificate supplied with provides the utmost protection from stray fields. each unit Like in most of our LVDTs, the DC-EC windings are vacuum impregnated with a specially formulated, high temperature, flexible resin, Applications and the coil assembly is potted inside its housing with a two-component Materials testing epoxy. This provides excellent protection against hostile environments Z-axis position feedback for punch- such as high humidity, vibration and shock. presses Available in a variety of stroke ranges from 0.05 to 10 inches, the DC- Microscope X-Y stage position control EC Series can be configured with a number of standard options including Medical imaging metric threaded core, guided core and small diameter/low mass core. Automotive suspension testing Captive core option: The DC-EC features an optional captive core design Flight simulators (available for most models) that greatly simplifies installation. The core rod and bearing assembly includes a Bronze bearing on the front end for self-alignment, while a PTFE sleeve allows low-friction travel through the stainless steel boreliner (spool tube). The core rod and the bearing assembly are both field serviceable. TE CONNECTIVITY SENSORS /// DC-EC SERIES REV. 8 11/2020 Page 1 DC-EC SERIES General purpose DC LVDT Performance Specifications ELECTRICAL SPECIFICATIONS Parameter DC-EC 050 DC-EC 125 DC-EC 250 DC-EC 500 DC-EC 1000 DC-EC 2000 DC-EC 3000 DC-EC 5000 DC-EC 10000 0.050 0.125 0.25 0.5 1 2 3 5 10 Stroke range 1.27 3.17 6.35 12.7 25.4 50.8 76.2 127 254 Sensitivity, VDC/inch 200 80 40 20 10 5 3.3 2.0 1.0 Sensitivity, VDC/mm 7.9 3.15 1.6 0.79 0.39 0.20 0.13 0.079 0.039 Frequency response Hertz -3dB 500 500 500 200 200 200 200 200 200 Input voltage 15VDC Input current 25mA Output at stroke ends 10VDC (Positive and increasing when the core is displaced from null position towards the cable) Non-linearity 0.25% of FR, maximum Output ripple 25mVRMS, maximum Stability 0.125% of FSO Output impedance 1 Ohm ENVIRONMENTAL SPECIFICATIONS & MATERIALS Operating temperature +32F to +160F 0C to 70C Survival temperature -65F to +200F -55C to 95C Shock survival 250 g (11ms half-sine) Vibration tolerance 10 g up to 2kHz Housing material AISI 400 Series stainless steel Electrical connection Cable with 4 conductors, 28AWG stranded copper, braided shield and polyurethane jacket, 39 inches 1 meter long. Shield is connected to case. IEC 60529 rating IP61 Notes: All values are nominal unless otherwise noted Dimensions are in inch mm unless otherwise noted FR: Full Range is the stroke range, end to end FR=2xS for S stroke range FSO (Full Scale Output): Largest absolute value of the outputs measured at the ends of the range Wiring Information TE CONNECTIVITY SENSORS /// DC-EC SERIES REV. 8 11/2020 Page 2
