SCD
55A0116
SPECIFICATION CONTROL DRAWING
Date Revision
Title WIRE, RADIATION-CROSSLINKED, MODIFIED ETFE-INSULATED,
10-25-16 J
LIGHTWEIGHT, GENERAL PURPOSE, 600 VOLT
This specification sheet forms a part of the latest issue of Raychem Specification 55A.
CONDUCTOR - NICKEL-COATED HIGH-STRENGTH INSULATION - RADIATION-CROSSLINKED,
COPPER ALLOY MODIFIED ETFE
TABLE I. CONSTRUCTION DETAILS
DIAMETER OF FINISHED WIRE
STRANDED
WIRE CONDUCTOR
MAXIMUM
PART NUMBER
MAXIMUM
CONDUCTOR
SIZE STRANDING
RESISTANCE DIAMETER
1/
(inch) WEIGHT
(AWG) (number x AWG)
AT 20C (inch)
(lbs/1000 ft.)
MINIMUM MAXIMUM (ohms/1000 ft.)
55A0116-28-* 28 7 x 36 .014 .016 79.0 .027 .002 .91
55A0116-26-* 26 19 x 38 .018 .020 49.4 .032 .002 1.4
55A0116-24-* 24 19 x 36 .023 .025 30.1 .037 .002 2.0
55A0116-22-* 22 19 x 34 .029 .031 18.6 .043 .002 2.9
55A0116-20-* 20 19 x 32 .037 .039 11.4 .050 .002 4.4
55A0116-18-* 18 19 x 30 .046 .051 7.1 .060 .002 6.6
55A0116-16-* 16 19 x 29 .052 .058 5.5 .068 .002 8.5
TABLE II. PERFORMANCE DETAILS
BEND TESTING
MANDREL DIAMETER WEIGHT
PART NUMBER (inch) ( 3%) (lb) ( 3%)
1/
IMMERSION, IMMERSION,
COLD COLD
LIFE CYCLE, AND LIFE CYCLE, AND
BEND BEND
ACCELERATED AGING ACCELERATED AGING
55A0116-28-* .250 .375 .125 .500
55A0116-26-* .375 .500 .125 .500
55A0116-24-* .375 .500 .250 1.00
55A0116-22-* .500 .750 .375 1.00
55A0116-20-* .500 .750 .500 1.00
55A0116-18-* .500 1.00 .500 1.00
55A0116-16-* .750 1.00 .750 1.00
Users should evaluate the suitability of this product for their application. Specifications are subject to change without notice.
Tyco Electronics Corporation also reserves the right to make changes in materials or processing, which do not affect compliance with any specification, without notification to Buyer.
1/ COLORS AND COLOR CODE DESIGNATORS SHALL BE IN ACCORDANCE WITH MIL-STD-681. OTHER CODES AND SUFFIXES MAY BE
ADDED TO THE PART NUMBER, AS NECESSARY, TO CAPTURE ANY ADDITIONAL REQUIREMENTS IMPOSED BY THE PURCHASE ORDER.
Raychem, TE Connectivity, TE Connectivity (logo), and TE (logo) are trademarks.
Raychem Wire & Cable
501 Oakside Avenue
DIMENSIONS ARE IN INCHES AND, UNLESS OTHERWISE DESIGNATED, ARE NOMINAL.
Redwood City, CA 94063-3800
Page 1 of 2
Phone: 1-800-522-6752
THIS SPECIFICATION SHEET TAKES PRECEDENCE OVER DOCUMENTS REFERENCED HEREIN.
Fax: 1-650-361-6297
REFERENCED DOCUMENTS SHALL BE OF THE ISSUE IN EFFECT ON DATE OF INVITATION FOR BID.
2015-2016 Tyco Electronics Corporation. All rights reserved.
Page Revision SCD
SPECIFICATION CONTROL DRAWING
55A0116
2 of 2 J
WIRE RATINGS AND ADDITIONAL REQUIREMENTS
TEMPERATURE RATING: 200C
Maximum continuous conductor temperature
VOLTAGE RATING: 600 volts (rms) at sea level
ACCELERATED AGING (CROSSLINKING PROOF): 300 3C for 7 hours
BLOCKING: 230 3C for 24 hours
COLOR: White preferred
CONCENTRICITY: 70% (minimum)
FLAMMABILITY: Procedure 1,
3 seconds (maximum), 3 inches (maximum); no flaming of facial tissue
HUMIDITY RESISTANCE: Insulation Resistance,
5000 megohms for 1000 ft. (minimum)
IDENTIFICATION, COLOR STRIPING, AND BAND DURABILITY:
125 cycles (250 strokes) (minimum), 500 g weight
IMMERSION: Diameter increase 5% (maximum); no cracking, no dielectric breakdown
INSULATION ELONGATION AND TENSILE STRENGTH:
Elongation, 75% (minimum)
2
Tensile Strength, 5000 lbf/in (minimum)
INSULATION FLAWS:
Spark Test, 5.7 kV (rms) at 3 kHz
Impulse Dielectric Test, 8.0 kV (peak)
INSULATION RESISTANCE:
5000 megohms for 1000 ft. (minimum)
INSULATION THICKNESS: 0.005 in. (minimum)
LIFE CYCLE: 230 3C for 500 hours
LOW TEMPERATURE-COLD BEND: -65 3C for 4 hours
SHRINKAGE: 230 3C for 6 hours, 0.125 in. (maximum) in 12 inches
SMOKE TEST: 250 5C, no visible smoke
SURFACE RESISTANCE: 500 meghoms-in. (minimum), both readings
THERMAL SHOCK RESISTANCE: 200 3C, 0.060 in. (maximum)
VOLTAGE WITHSTAND (Post Environmental): 2500 volts (rms), 60 Hz
WRAP TEST: 313 3C for 2 hours
1/ PART NUMBER:
The in the part numbers in Tables I and II shall be replaced by a color code designator.
Example: AWG 22, white: 55A0116-22-9
AWG 22, white with a black stripe: 55A0116-22-90
1/ See footer section on page 1
