44A0111-24-9 Hook Up Wire, Spec 44, 600V Hook Up Wire Voltage Rating, 24AWG Wire Size, White Hook Up Wire Wire Color, Operating Temperature Range -65 150 C 44A0111-24-9 ACTIVE Raychem TE Internal : 2820493017 Hook Up Wire, Spec 44, 600V Hook Up Wire Voltage Rating, 24AWG Wire Size, White Hook Up Wire Wire Color, Operating Temperature Range -65 150 C View on TE.com> Wire & Cable > Hook Up Wire Hook Up Wire Cable Type: Spec 44 Hook Up Wire Voltage Rating: 600 V Hook Up Wire Insulation Material: Modified Radiation Cross-linked PVDF Hook Up Wire Conductor Material: Tin-Coated Copper Hook Up Wire Wire Color: White Features Product Type Features Cable Style Primary Product Type Cable Product Classification Cable - High Performance - Spec 44, 55 & RCW Hook Up Wire Cable Type Spec 44 Configuration Features Number of Conductors 1 Number of Strands 19 Electrical Characteristics Hook Up Wire Voltage Rating 600 V Body Features Hook Up Wire Insulation Material Modified Radiation Cross-linked PVDF Hook Up Wire Conductor Material Tin-Coated Copper Hook Up Wire Wire Color White Dimensions Overall Outside Diameter 1.02 mm .04 in Wire Diameter 1.02 mm .04 in Conductor Diameter .64 mm .025 in 10/10/2021 11:07PM Page1 For support call+1 800 522 6752 44A0111-24-9 Hook Up Wire, Spec 44, 600V Hook Up Wire Voltage Rating, 24AWG Wire Size, White Hook Up Wire Wire Color, Operating Temperature Range -65 150 C Conductor Diameter .64 mm .025 in Strand Size 36 AWG Wire Size 24 AWG Usage Conditions Operating Temperature Range -65 150 C Other Wire Source United Kingdom Product Compliance For compliance documentation, visit the product page on TE.com> EU RoHS Directive 2011/65/EU Compliant EU ELV Directive 2000/53/EC Compliant China RoHS 2 Directive MIIT Order No 32, 2016 No Restricted Materials Above Threshold EU REACH Regulation (EC) No. 1907/2006 Current ECHA Candidate List: JUL 2021 (219) Candidate List Declared Against: JUL 2021 (219) Does not contain REACH SVHC Halogen Content Out of Scope - excluded from Halogen requirements Solder Process Capability Not applicable for solder process capability Product Compliance Disclaimer This information is provided based on reasonable inquiry of our suppliers and represents our current actual knowledge based on the information they provided. This information is subject to change. The part numbers that TE has identified as EU RoHS compliant have a maximum concentration of 0.1% by weight in homogenous materials for lead, hexavalent chromium, mercury, PBB, PBDE, DBP, BBP, DEHP, DIBP, and 0.01% for cadmium, or qualify for an exemption to these limits as defined in the Annexes of Directive 2011/65/EU (RoHS2). Finished electrical and electronic equipment products will be CE marked as required by Directive 2011/65/EU. Components may not be CE marked. Additionally, the part numbers that TE has identified as EU ELV compliant have a maximum concentration of 0.1% by weight in homogenous materials for lead, hexavalent chromium, and mercury, and 0.01% for cadmium, or qualify for an exemption to these limits as defined in the Annexes of Directive 2000/53/EC (ELV). Regarding the REACH Regulation, the information TE provides on SVHC in articles for this part number is based on the latest European Chemicals Agency (ECHA) Guidance on requirements for substances in articles posted at this URL:
