SCD 55A0122 SPECIFICATION CONTROL DRAWING Title Date Revision TWO CONDUCTOR CABLE, UNSHIELDED, UNJACKETED, 12-11-15 E GENERAL PURPOSE, 600 VOLT This specification sheet forms a part of the latest issue of Raychem Specification 55A. COMPONENT WIRES - 55A0112 CABLE CONSTRUCTION DETAILS OUTSIDE DIAMETER CONDUCTOR MAXIMUM PART NUMBER (inch) SIZE WEIGHT 1/ (AWG) (lbs/1000 ft.) NOMINAL MAXIMUM 55A0122-30-* 30 .048 .052 1.4 55A0122-28-* 28 .054 .058 1.9 55A0122-26-* 26 .064 .068 2.9 55A0122-24-* 24 .074 .078 4.1 55A0122-22-* 22 .086 .090 5.7 55A0122-20-* 20 .100 .104 8.8 55A0122-18-* 18 .120 .124 13.3 55A0122-16-* 16 .136 .140 16.9 55A0122-14-* 14 .170 .176 26.5 55A0122-12-* 12 .206 .212 40.2 55A0122-10-* 10 .256 .268 65.9 CABLE RATINGS AND ADDITIONAL REQUIREMENTS TEMPERATURE RATING: 200C 1/ PART NUMBER: Maximum continuous conductor temperature The in the part numbers above shall be replaced by VOLTAGE RATING: 600 volts (rms) at sea level color code designators with a slash separating the DIELECTRIC WITHSTAND: 1500 volts (rms), 60 Hz component wire colors. INSULATION FLAWS: Example: AWG 22, black and brown component wires: Spark Test, 5.7 kV (rms) at 3 kHz 55A0122-22-0/1 Impulse Dielectric Test, 8.0 kV (peak) NOTE: Nominal values are for information only. Nominal values are not requirements. Users should evaluate the suitability of this product for their application. Specifications are subject to change without notice. Tyco Electronics Corporation also reserves the right to make changes in materials or processing, which do not affect compliance with any specification, without notification to Buyer. 1/ COLORS AND COLOR CODE DESIGNATORS SHALL BE IN ACCORDANCE WITH MIL-STD-681. HOWEVER, DUE TO LENGTH LIMITATIONS OF THE RAYCHEM PART NUMBER, AN ALTERNATIVE COLOR CODE MAY REPLACE MIL-STD-681 COLOR CODE DESIGNATORS. (EXAMPLE: 901/902.. MAY BE REPLACED BYAxx.) OTHER CODES AND SUFFIXES MAY BE ADDED TO THE PART NUMBER, AS NECESSARY, TO CAPTURE ANY ADDITIONAL REQUIREMENTS IMPOSED BY THE PURCHASE ORDER. Raychem, TE Connectivity, TE connectivity (logo), and TE (logo) are trademarks. Raychem Wire & Cable 501 Oakside Avenue DIMENSIONS ARE IN INCHES AND, UNLESS OTHERWISE DESIGNATED, ARE NOMINAL. Page 1 of 1 Redwood City, CA 94063-3800 Phone: 1-800-227-8816 THIS SPECIFICATION SHEET TAKES PRECEDENCE OVER DOCUMENTS REFERENCED HEREIN. Fax: 1-650-361-6297 REFERENCED DOCUMENTS SHALL BE OF THE ISSUE IN EFFECT ON DATE OF INVITATION FOR BID. 2009-2015 Tyco Electronics Corporation. All rights reserved. X-ON Electronics Largest Supplier of Electrical and Electronic Components Click to view similar products for Multi-Conductor Cables category: Click to view products by TE Connectivity manufacturer: Other Similar products are found below : 89182-010-1000 89705-008-500 6000FE-877-1000 CS2885-000 M27500-20SP2S23 6300FE-877-U1000 6309UE-877-1000 M3905-BK005 6502FE 8771000 6541PA-008-U1000 CV6807-000 CW9530-000 CX6543-000 CXA-0066-20-4-9CS2973 CXA-0078-16-1-9CS2405 CXA- 0078-22-4-9CS2405 CXA-0078-24-4-9CS2405 CXA-0140-16-6/9-9CS2405 CY0660-000 720451-000 752687-000 768146-000 773159-000 82841-877-5000 83318E-009-500 8348-060-500 83559-002-1000 83653-002-5000 83659-002-1000 83709-002-1000 8404-060-500 8469 060100 858171-000 8628-060-500 868361-001 8730-060-1000 8737-060-U1000 8747-060-100 8747-060-1000 8769-060-1000 8775-060- 500 877541-000 8780-060-1000 8782-001-U1000 88444-002-1000 9159-060-500 939870-000 9423 060U500 9444 060U1000 9497 0001000
