55PC6121 SPECIFICATION CONTROL DRAWING Date Revision TITLE WIRE, RADIATION-CROSSLINKED, MODIFIED, ETFE-INSULATED, 03-16-00 C TIN-COATED COPPER, GENERAL PURPOSE, LIGHT AIRFRAME, 600 VOLT This specification sheet forms a part of the latest issue of Raychem Specifiction 55PC. CONDUCTOR - TIN-COATED COPPER INSULATION - RADIATION-CROSSLINKED, 30 MICRO INCH THICKNESS MINIMUM MODIFIED ETFE COLOR - White with 2 black stripes CONSTRUCTION DETAILS FINISHED WIRE CONDUCTOR DIAMETER ( in.) DIAMETER WEIGHT WIRE CONDUCTOR ( in.) ( lbs/1000 ft. ) MAXIMUM UPPER PART NUMBER SIZE STRANDING LOWER RESISTANCE TARGET LOWER LOWER UPPER UPPER (AWG) (number x AWG) SPEC SPEC AT 20C TARGET TARGET VALUE SPEC SPEC SPEC SPEC LIMIT LIMIT (ohms/1000 ft.) VALUE VALUE LIMIT LIMIT LIMIT LIMIT 55PC6121-22-900 22 19 x 34 .0285 .0293 .0301 16.2 .0455 .0472 2.74 2.90 3.06 .0438 55PC6121-20-900 20 19 x 32 .0365 .0375 .0385 9.88 .0523 .0540 .0557 4.19 4.38 4.57 55PC6121-18-900 18 19 x 30 .0452 .0464 .0476 6.23 .0616 .0635 .0654 6.28 6.59 6.90 WIRE RATINGS AND ADDITIONAL REQUIREMENTS SHRINKAGE: 230 3C for 1 hour, 0.125 in.(maximum) in 12 in. TEMPERATURE RATING: 150C Maximum continuous conductor temperature SPOOLING: VOLTAGE RATING: 600 volts (rms) Minimum lengths, 500 ft. CROSSLINK VERIFICATION: 300 3C for 1 hour Place orange flag on each splice IDENTIFICATION AND COLOR STRIPING DURABILITY: STRIPE WIDTH: .022 in. (maximum) STRIPE INTERVALS: Per MIL-STD-681 ( 2 inch maximum) 125 cycles (250 strokes) (minimum), 500 g weight INSULATION ELONGATION AND TENSILE STRENGTH: VOLTAGE WITHSTAND TEST (POST ENVIRONMENTAL): Total Insulation, 2500 volts (rms) Elongation, 50% (minimum) Tensile Strength, 5000 lbf/in (minimum) MARKING: Mark wire in green ink at 1.5 inch (nominal) distance between marks. Example: 18 AWG INSULATION FLAWS: Impulse Dielectric Test, 8.0 kV (peak) Mark shall be read horizontally for AWG size 20 and 18 INSULATION THICKNESS: .008 in. (nominal) total insulation Mark shall be read vertically for AWG size 22 NOTES: - THIS WIRE MEETS ALL REQUIREMENTS OF BMS13-48T10C1, EXCEPT IDENTIFICATION AS MODIFIED HEREIN. - STRIPING INK MEETS RAYCHEM SPECIFICATION RT1404 WHICH INCLUDES IMMERSED I.R. AND DWV TESTING. COLORS, STRIPES AND COLOR CODE DESIGNATORS SHALL BE IN ACCORDANCE WITH MIL-STD-681. 300 Constitution Drive, Menlo Park, California 94025 THIS SPECIFICATION SHEET TAKES PRECEDENCE OVER DOCUMENTS REFERENCED HEREIN. 1-800-2 Raychem Fax: 1-650-361-6297 Page 1 of 1 REFERENCED DOCUMENTS SHALL BE OF THE ISSUE IN EFFECT ON DATE OF INVITATION FOR BID.
