SPECIFICATION CONTROL DRAWING 2020E0421 5-17-21 120 OHM, AWG 20, 19 STRANDS OF AWG 32, Date: OPTIMIZED SHIELD, TWINAXIAL CABLE CHEMINAX D Revision: THIS SPECIFICATION SHEET FORMS A PART OF THE LATEST ISSUE OF RAYCHEM SPECIFICATION 1200. CONSTRUCTION DETAILS ELECTRICAL CHARACTERISTICS DIMENSIONS ARE NOMINAL VALUES IN INCHES, UNLESS CHARACTERISTIC IMPEDANCE 120 12 ohms, Method D at 1 MHz OTHERWISE DESIGNATED. with shield grounded MUTUAL CAPACITANCE 10.5 pF/ft. (nominal) CONDUCTORS VELOCITY OF PROPAGATION 78% (nominal) AWG 20, .0400 SURFACE TRANSFER IMPEDANCE 50 milliohms/meter (maximum) 19 Strands of AWG 32, (per SAE AS85485) at 100 kHz to 20 MHz Tin-Coated Copper DIELECTRICS .109 ADDITIONAL REQUIREMENTS Foamed FEP Colors - White/Light Blue FILLER .070 ELECTRICAL Radiation-Crosslinked, Modified ETFE CONDUCTOR RESISTANCE 9.53 ohms/1000 ft. (nominal) (prior to cabling) INSULATION RESISTANCE 10,000 megohms (minimum) for 1000 ft. DRAINWIRE JACKET FLAWS .0400 AWG 20, SPARK TEST 1.0 kV (rms) 19 Strands of AWG 32, IMPULSE TEST 6.0 kV (peak) Tin-Coated Copper VOLTAGE WITHSTAND (DIELECTRIC) 1500 volts (rms) SHIELD .239 AWG 36, Tin-Coated Copper, ENVIRONMENTAL Optimized FLAMMABILITY Method B HEAT SHOCK 225C LOW TEMPERATURE-COLD BEND -55C/8.00 inch mandrel VOLTAGE WITHSTAND 1000 volts (rms), 1 minute (Post Environmental) JACKET PHYSICAL .289 Modified FEP INSULATION (DIELECTRIC) (prior to cabling) ELONGATION 50% (minimum) 2 TENSILE STRENGTH 600 lbf/in (minimum) JACKET ELONGATION 200% (minimum) 2 TENSILE STRENGTH 2000 lbf/in (minimum) JACKET THICKNESS .025 inch (nominal) Designate outer jacket color with a dash number in accordance with MIL-STD-681. Unless otherwise specified, outer jacket color WEIGHT 59.3 lbs/1000 ft. (nominal) will be translucent white designated by a-9 appended to the part number, (e.g. 2020E0421-9X). ENGINEERING REFERENCE Other codes and suffixes may be added to the part number, as necessary, to capture any additional requirements imposed by TEMPERATURE RATING 150C (maximum) the purchase order. Users should evaluate the suitability of this product for their application. Specifications are subject to change without notice. TE Connectivity also reserves the right to make changes in materials or processing, which do not affect compliance with any specification, without notification to Buyer. Page 1 of 1 Cheminax, Raychem, TE Connectivity, TE connectivity (logo), and TE (logo) are trademarks. Raychem Wire & Cable THIS SPECIFICATION SHEET TAKES PRECEDENCE OVER DOCUMENTS REFERENCED HEREIN. 501 Oakside Avenue REFERENCED DOCUMENTS SHALL BE OF THE ISSUE IN EFFECT ON DATE OF INVITATION FOR BID. Redwood City, California 94063-3800 2014-2021 TE Connectivity Ltd. family of companies. All rights reserved. Phone: 1-800-227-8816 X-ON Electronics Largest Supplier of Electrical and Electronic Components Click to view similar products for Coaxial Cables category: Click to view products by TE Connectivity manufacturer: Other Similar products are found below : 89880-003-1000 CY2389-000 8221-010-U1000 9116-010-U500 1322R-010-1000 1807A-B59-U1000 2020K8421-9X-CS3417 9251-010- 1000 9275-010-U1000 935240-000 980704-001 CF2823-000 33312-010-500 CZ1589-000 5022W0809-0CS3263 10610-4-4 EF8108-000 1673B TIN100 672525-001 144517-000 735A1-008-1000 8212-010-U500 480414-000 7915A 009U1000 5024A1311-0 1281S5 010250 1530A 010U1000 9248 010U1000 9244 0101000 1694A 0081000 1190A 0101000 8241F J5C1000 1674A TIN50 7915A 0091000 TRCH- 50-2 9066 0031000 7805R 008100 1674A TIN100 9116SB 0101000 9271 0061000 1613A 0101000 1807A B591000 5339Q5 009U500 539945 0091000 9116R 0101000 89207 010100 9058 0101000 8241A 0101000 DA7805R 0101000 C6424
