55FB2531 SPECIFICATION CONTROL DRAWING Date Revision TITLE THREE CONDUCTOR CABLE, FLAT BRAID SHIELDED, JACKETED, FILTER LINE - ELECTROLOSS 7-30-10 E This specification sheet forms a part of the latest issue of Raychem Specification 55F . JACKET - RADIATION-CROSSLINKED, COMPONENT WIRES - 55FA0511 SHIELD - TIN-COATED COPPER MODIFIED CONDUCTIVE ETFE CABLE CONSTRUCTION DETAILS JACKET FLEXURE SHIELD JACKET THICKNESS OUTSIDE DIAMETER ENDURANCE CONDUCTOR MAXIMUM PART NUMBER STRAND (in.) (in.) MANDREL SIZE WEIGHT 1/ THICKNESS DIAMETER (AWG) (lbs/1000 ft.) ( .0004 in.) (in.) ( 3%) MINIMUM NOMINAL NOMINAL MAXIMUM 55FB2531-22-* 22 .0015 .006 .008 .133 .140 17.7 .325 55FB2531-20-* 20 .0015 .006 .008 .150 .158 24.0 .325 55FB2531-18-* 18 .0015 .006 .008 .174 .183 33.9 .500 55FB2531-16-* 16 .0015 .006 .008 .191 .201 42.3 .500 55FB2531-14-* 14 .0015 .007 .009 .230 .242 59.7 .500 CABLE RATINGS AND ADDITIONAL REQUIREMENTS TEMPERATURE RATING: 150C JACKET FLAWS: Not Applicable Maximum continuous conductor temperature JACKET FLEXURE ENDURANCE: 10 cycles, no cracking VOLTAGE RATING: 600 volts (rms) at sea level LIFE CYCLE: 200 3C for 168 hours BLOCKING: 200 3C for 6 hours LOW TEMPERATURE-COLD BEND: -65 2C for 4 hours CROSSLINKING PROOF TEST: 300 3C for 7 hours SHIELD COVERAGE: 85% (minimum) FLAMMABILITY: 3 seconds (maximum) 3 in. (maximum) VOLTAGE WITHSTAND (DIELECTRIC): no flaming of facial tissue Conductor to conductor and shield, 1500 volts (rms), 60 Hz FLUORIDE EXTRACTION: VOLTAGE WITHSTAND (Post Environmental): Not Applicable 70 2 C for 168 hours, 250 ppm (maximum) IDENTIFICATION AND COLOR STRIPING DURABILITY: PART NUMBER: 125 cycles (250 strokes) (minimum), 500 g weight The in the part numbers above shall be replaced by color code JACKET COLOR: Black designators with a slash separating the component wire colors and a dash JACKET ELONGATION AND TENSILE STRENGTH: separating the component wire colors from the jacket color. Violet shall be Elongation, 50% (minimum) light violet and the designator shall be 7L. Colors shown do not Tensile Strength, 3500 lbf/in (minimum) necessarily reflect the sequence of manufacturing. Example: AWG 22, light violet, light violet with an orange stripe and light NOTE: Nominal values are for information only. violet with a blue stripe component wires, black jacket: Nominal values are not requirements. 55FB2531-22-7L/7L3/7L6-0 This product meets or exceeds all requirements of SAE AS85485, less identification. Internal wire sizes 22-14 AWG meet or exceed all requirements of SAE AS85485/9, less identification. Users should evaluate the suitability of this product for their application. Specifications are subject to change without notice. Tyco Electronics also reserves the right to make changes in materials or processing, which do not affect compliance with any specification, without notification to Buyer. 1/ COLORS AND COLOR CODE DESIGNATORS SHALL BE IN ACCORDANCE WITH MIL-STD-681. HOWEVER, DUE TO LENGTH LIMITATIONS OF THE RAYCHEM PART NUMBER, AN ALTERNATIVE COLOR CODE MAY REPLACE MIL-STD-681 COLOR CODE DESIGNATORS. (EXAMPLE: 901/902... MAY BE REPLACED BY Axxx.) OTHER CODES AND SUFFIXES MAY BE ADDED TO THE PART NUMBER AS NECESSARY, TO CAPTURE ANY ADDITIONAL REQUIREMENTS IMPOSED BY THE PURCHASE ORDER. The TE logo, Tyco Electronics, Electroloss and Raychem are trademarks. Raychem Wire & Cable 501 Oakside Avenue DIMENSIONS ARE IN INCHES, AND UNLESS OTHERWISE DESIGNATED ARE NOMINAL Redwood City, CA 94063-3800 Page 1 of 1 Phone: 1-800-227-8816 THIS SPECIFICATION SHEET TAKES PRECEDENCE OVER DOCUMENTS REFERENCED HEREIN. Fax: 1-650-361-6297 REFERENCED DOCUMENTS SHALL BE OF THE ISSUE IN EFFECT ON DATE OF INVITATION FOR BID. 2008-2010 Tyco Electronics Corporation. All rights reserved.X-ON Electronics Largest Supplier of Electrical and Electronic Components Click to view similar products for Multi-Conductor Cables category: Click to view products by TE Connectivity manufacturer: Other Similar products are found below : 8916-GRY-100 8917-BLK-100 8918-GRN/YEL-100 8920-BRN-1000 8920-RED-1000 89907-LT-DEC/GRY-500 CR3909-000 CR3927- 000 01342.35T.01 01364.35T.01 CS2885-000 CS8782-000 CS9912-000 6200UE-NAT-U1000 CTC-0062-20-9/5-9 CTC-0062-22-9/5-9 6304FE-877-U500 6309UE-877-1000 6320UE-NAT-U1000 644833-000 6502FE 8771000 6504UE-877-U1000 CW9530-000 CX6543-000 CXA-0066-20-4-9CS2973 CXA-0078-16-1-9CS2405 CXA-0078-22-4-9CS2405 CXA-0078-24-4-9CS2405 CXA-0140-16-6/9-9CS2405 CY0660-000 706/2R-BLACK-EACH 720451-000 730859-000 MCC-USB-4-250 752687-000 768146-000 773159-000 7934A-BLK-1000 8125-CHR-100 8164-CHR-1000 820457-000 8205-CHR-1000 8240-BLK-U1000 82723-NAT-1000 82907-NAT-500 83003-YEL-500 83005-WHT-500 83006-DK-GRN-100 83008-WHT-1000 83009-BLK-100
