CPF0603B10KE1 TE Connectivity

Thin Film Precision Resistors Type CPF Series Key Features Thin film precision resistors with TC s to 15ppm and tolerances to 0.05%. Wide range of case sizes from 0201 to 2512 Suitable for all applications where close accuracy and stability are essential Terminal finish electroplated 100% matte Sn Applications The CPF series is a high stability precision chip resistor range offering various power dissipations relating to a wide range of chip sizes. The CPF Communications series offers TCR s down to 15ppm/C and resistance tolerances to 0.1%. Industrial Controls Standard values are within the IEC 63 E96 and E24 value grids. The CPF has accurate and uniform physical dimensions to facilitate placement Instrumentation Medical Electrical Characteristics Chip Size 0201 Rated Power 70C 0.03125W Min. 49R9 49R9 49R9 49R9 49R9 49R9 Resistance Range Max 75K 75K 75K 75K 75K 75K Tolerance 0.1 0.5 1 Code Letter B D F Selection series E24 & E96 Temp. Coefficient (ppm/C) 25 50 25 50 25 50 Code Letter E C E C E C Operating Voltage (Max) 15V Max. Overload Voltage 30V Operating Temp. Range -55 ~ +155C Insulation Resistance dry min. >M Stability 0.5% Dimensions in Dimensions Shown for 1773200 Rev N 03/2020 For Email, phone or live chat, millimetres unless reference purposes only. go to: www.te.com/help otherwise specified Specifications subject to change Thin Film Precision Resistors Chip Size 0402 Rated Power 70C 0.063W Resistance Min. 49R9 4R02 4R02 49R9 4R02 49R9 4R02 Range Max 20K 100K 511K 100K 511K 100K 511K Tolerance (%) 0.05 0.1 0.5 1 Code Letter A B D F Selection series E24 & E96 T.C.R. (ppm/C) 15 25 50 15 25 50 15 25 50 15 25 50 Code Letter D E C D E C D E C D E C Max Operating Volt. 25V Max. Overload Volt. 50V Op. Temp. Range -55 ~ +155C Insulation Resistance >M Stability 0.5% Chip Size 0603 Rated Power 70C 0.063W Resistance Min. 4R7 4R7 1R0 4R7 1R0 4R7 1R0 Range Max 332K 511K 1M0 511K 1M0 511K 1M0 Tolerance (%) 0.05 0.1 0.5 1 Code Letter A B D F Selection series E24 & E96 T.C.R. (ppm/C) 15 25 50 15 25 50 15 25 50 15 25 50 Code Letter D E C D E C D E C D E C Max Operating Volt. 50V Max. Overload Volt. 100V Op. Temp. Range -55 ~ +155C Insulation Resistance >M Stability 0.5% Chip Size 0805 Rated Power 70C 0.1W Resistance Min. 4R7 4R7 1R0 4R7 1R0 4R7 1R0 Range Max 1M0 1M0 2M0 1M0 2M0 1M0 2M0 Tolerance (%) 0.05 0.1 0.5 1 Code Letter A B D F Selection series E24 & E96 T.C.R. (ppm/C) 15 25 50 15 25 50 15 25 50 15 25 50 Code Letter D E C D E C D E C D E C Max Operating Volt. 100V Max. Overload Volt. 200V Op. Temp. Range -55 ~ +155C Insulation Resistance >M Stability 0.5% Dimensions in Dimensions Shown for 1773200 Rev N 03/2020 For Email, phone or live chat, millimetres unless reference purposes only. go to: www.te.com/help otherwise specified Specifications subject to change
