SCD 55PC0233 SPECIFICATION CONTROL DRAWING Title Date Revision THREE CONDUCTOR CABLE, UNSHIELDED, UNJACKETED, GENERAL PURPOSE, 600 VOLT 6-10-16 E This specification sheet forms a part of the latest issue of Raychem Specification 55PC. COMPONENT WIRES 55PC0213 CONSTRUCTION DETAILS DIAMETER WEIGHT CONDUCTOR (inch) (lbs/1000 ft) PART NUMBER SIZE 1/ (AWG) LOWER SPEC TARGET UPPER SPEC TARGET UPPER SPEC LIMIT VALUE LIMIT VALUE LIMIT 55PC0233-26-* 26 .070 .074 .078 4.18 4.60 55PC0233-24-* 24 .081 .085 .089 6.02 6.30 55PC0233-22-* 22 .094 .098 .102 8.82 9.13 55PC0233-20-* 20 .112 .116 .121 13.32 13.68 55PC0233-18-* 18 .132 .137 .142 20.04 20.66 55PC0233-16-* 16 .148 .153 .158 25.46 26.13 55PC0233-14-* 14 .180 .185 .191 39.17 40.06 55PC0233-12-* 12 .219 .226 .232 60.01 61.19 55PC0233-10-* 10 .269 .278 .287 94.65 96.77 55PC0233-8-* 8 .408 .423 .438 173. 181. 55PC0233-6-* 6 .504 .523 .542 273. 286. 55PC0233-4-* 4 .648 .672 .696 444. 464. 55PC0233-2-* 2 .799 .827 .858 695. 724. 55PC0233-0-* 0 .970 1.01 1.04 1043. 1103. CABLE RATINGS AND ADDITIONAL REQUIREMENTS TEMPERATURE RATING: 200C 1/ PART NUMBER: Maximum continuous conductor temperature The * in the part numbers above shall be replaced by color code VOLTAGE RATING: 600 volts (rms) at sea level designators with a slash separating the component wire colors. Colors INSULATION FLAWS: shown do not necessarily reflect the sequence of manufacturing. Spark Test, 3.0 kV (rms) Example: AWG 16, red, yellow and blue component wires Impulse Dielectric Test, 8.0 kV (peak) 55PC0233-16-2/4/6 Users should evaluate the suitability of this product for their application. Specifications are subject to change without notice. Tyco Electronics also reserves the right to make changes in materials or processing, which do not affect compliance with any specification, without notification to Buyer. 1/ COLORS AND COLOR CODE DESIGNATORS SHALL BE IN ACCORDANCE WITH MIL-STD-681. HOWEVER, DUE TO LENGTH LIMITATIONS OF THE RAYCHEM PART NUMBER, AN ALTERNATIVE COLOR CODE MAY REPLACE MIL-STD-681 COLOR CODE DESIGNATORS. (EXAMPLE: 901/902.. MAY BE REPLACED BYAxx.) OTHER CODES AND SUFFIXES MAY BE ADDED TO THE PART NUMBER, AS NECESSARY, TO CAPTURE ANY ADDITIONAL REQUIREMENTS IMPOSED BY THE PURCHASE ORDER. Raychem, TE Connectivity, TE connectivity (logo), and TE (logo are trademarks. Raychem Wire & Cable 501 Oakside Avenue DIMENSIONS ARE IN INCHES AND, UNLESS OTHERWISE DESIGNATED, ARE NOMINAL. Page 1 of 1 Redwood City, CA 94063-3800 Phone: 1-800-227-8816 THIS SPECIFICATION SHEET TAKES PRECEDENCE OVER DOCUMENTS REFERENCED HEREIN. Fax: 1-650-361-6297 REFERENCED DOCUMENTS SHALL BE OF THE ISSUE IN EFFECT ON DATE OF INVITATION FOR BID. 20072016 Tyco Electronics Corporation. All rights reserved. X-ON Electronics Largest Supplier of Electrical and Electronic Components Click to view similar products for Multi-Conductor Cables category: Click to view products by TE Connectivity manufacturer: Other Similar products are found below : 89182-010-1000 6000FE-877-1000 M27500-20SP2S23 6300FE-877-U1000 6309UE-877-1000 6502FE 8771000 6541PA-008-U1000 CV6807-000 CW9530-000 CX6543-000 CXA-0066-20-4-9CS2973 CXA-0078-16-1-9CS2405 CXA-0078-22-4-9CS2405 CXA-0078-24-4- 9CS2405 CXA-0140-16-6/9-9CS2405 CY0660-000 720451-000 752687-000 82841-877-5000 8348-060-500 83559-002-1000 83653-002- 5000 83659-002-1000 83709-002-1000 8404-060-500 8469 060100 8628-060-500 868361-001 8730-060-1000 8737-060-U1000 8747-060- 100 8747-060-1000 8769-060-1000 8775-060-500 877541-000 8780-060-1000 88444-002-1000 9159-060-500 939870-000 9423 060U500 9444 060U1000 9497 0001000 9515-060-1000 9520-060-1000 9524-060-1000 9546-060-500 9572-002-U500 9774-060-1000 1213F-D15- A1000 1213F-009-A1000
