RP73PF2A7K5BTDF TE Connectivity

SMD High Power Precision Resistors Type RP73 Series Key Features n High precision - tolerances down to 0.05% n Low TCR - down to 5ppm/C n Stable high frequency performance n Operating temperature -55C to +155C n Increased power rating - up to 1.0W n Up to 200V DC operating voltage n Range of packaging options n Terminal finish - electroplated 100% matte Sn Applications The RP73 resistor series is a stable thin film chip resistor range offering increased power dissipation, higher temperature capabilities and increased working voltages compared to the n Communications standard RN73 series. The resistor is produced by sputtering a metal film onto high grade n Instrumentation alumina and protecting with three complete printed layers. Values are normally offered in E96 n Industrial Controls and E24 series. The RP73 resistor has accurate and uniform physical dimensions to reduce n Medical placement problems. Characteristics - Electrical - RP73 Series - Standard 0402 0603 Rated Power 70C: 0.063W 0.1W Resistance Range (Ohms) Min: 49R9 49R9 49R9 49R9 49R9 49R9 10R 49R9 49R9 10R 24R9 4R7 24R9 4R7 4R7 24R9 4R7 4R7 Max: 5K0 15K 100K 5K0 15K 70K 255K 5K0 15K 255K 15K 332K 15K 332K 1M0 15K 332K 1M0 Tolerance (%): 0.05 0.1 0.5 / 1 0.05 0.1 0.5 / 1 Code Letter: AB D / F AB D / F Selection Series: E24 & E96 E24 & E96 Temp. Coefficient (ppm/C): 5 10 15 25 50 5 10 15 25 50 5 10 15 25 50 5 10 15 2550 5 10 15 25 50 5 1015 25 50 Code Letter: ACDFG A C D F G A CDFG A CDFG A CDFG A CDFG Limiting Element Voltage: 25V 75V Max. Overload Voltage: 50V 150V Operating Temp. Range: -55 to +155C -55 to +155C Climatic Category (C): 55/125/55 55/125/55 Insulation Resistance Dry Min: 1000M 1000M Stability: 0.5% 0.5% 0805 1206 Rated Power 70C: 0.125W 0.25W Resistance Range (Ohms) Min: 24R9 4R7 24R9 4R7 4R7 24R9 4R7 4R7 1R0 24R9 4R7 Max: 30K 511K 30K 511K 1M0 30K 511K 1M0 1M0 50K 1M0 Tolerance (%): 0.05 0.1 0.5 / 1 0.05 / 0.1 / 0.5 / 1 Code letter: AB D / F A / B / D / F Selection Series: E24 & E96 E24 & E96 Temp. Coefficient (ppm/C): 5 10 15 25 50 5 10 15 25 50 5 10 15 25 50 5 10 15 25 50 Code Letter: ACD F G A C DFG A C D F G A C D F G Limiting Element Voltage: 150V 200V Max. Overload Voltage: 300V 400V Operating Temp. Range: -55 to +155C -55 to +155C Climatic Category (C): 55/125/55 55/125/55 Insulation Resistance Dry Min: 1000M 1000M Stability: 0.5% 0.5% 1773272 CIS WR 04/2012 Dimensions are in millimeters Dimensions are shown for For email, phone or live chat, go to: te.com/help and inches unless otherwise reference purposes only. specified. Values in brackets Specifications subject are standard equivalents. to change.SMD High Power Precision Resistors Type RP73 Series 1210 2010 2512 Rated Power 70C: 0.3W 0.3W 1W Resistance Range (Ohms) Min: 24R9 4R7 24R9 4R7 4R7 1R0 Max: 50K 1M0 50K 1M0 100R 100R Tolerance (%): 0.05 / 0.1 / 0.5 / 1 0.05 / 0.1 / 0.5 / 1 0.1 0.5 / 1 Code Letter: A / B / D / F A / B / D / F B D / F Selection Series: E24 & E96 E24 & E96 E24 & E96 Temp. Coefficient (ppm/C): 5 10 15 25 50 5 10 15 25 50 25 50 25 50 Code Letter: ACD F G A C D F G F G F G Limiting Element Voltage: 200V 200V 200V Max. Overload Voltage: 400V 400V 400V Operating Temp. Range: -55 to +155C -55 to +155C -55 to +155C Climatic Category (C): 55/125/55 55/125/55 55/125/55 Insulation Resistance Dry Min: 1000M 1000M 1000M Stability: 0.5% 0.5% 0.5% Characteristics - Electrical - RP73P Series - High Power 0603 0805 Rated Power 70C: 0.166W 0.25W Resistance Range (Ohms) Min: 10R 10R Max: 332K 500K Tolerance (%): 0.1 0.5 1 0.1 0.5 1 Code Letter: B D FB D F Selection Series: E24 & E96 E24 & E96 Temp. Coefficient (ppm/C): 25 50 25 50 25 50 25 50 25 50 25 50 Code Letter: FG FG F G F G F G F G Limiting Element Voltage: 100V 150V Max. Overload Voltage: 150V 300V Operating Temp. Range: -55 to +155C -55 to +155C Climatic Category (C): 55/125/55 55/125/55 Insulation Resistance Dry Min: 1000M 1000M Stability: 0.5% 0.5% Characteristics - Environmental Requirement Item Test Method Tol. 0.05% Tol. > 0.05% Temperature Coefficient As per TCRs specified in value range table on page 1 +25/-55/+25/+125/+25C of Resistance (TCR): R 0.05% R 0.2% RCWV* 2.5 or max. overload Short Time Overload: voltage for 5 seconds R 0.2% for high power rating Insulation Resistance: >1000M Apply 100VDC for 1 minute R 0.05% R 0.2% 70 2C, max. working voltage Endurance: >7k R 0.5% for 1000hrs with 1.5hrs ON and 0.5 hrs OFF R 0.5% for high power rating R 0.05% R 0.3% 40 2C, 90 - 95% R.H. max. working voltage Damp Heat with Load: hrs with 1.5hrs ON and 0.5hrs OFF R 0.5% for high power rating Bending Strength: R 0.05% R 0.2% Bending amplitude 3mm for 10 seconds Solderability: 95% min. coverage 245 5C for 3 seconds Resistance to Soldering Heat: R 0.05% R 0.2% 260 5C for 10 seconds Dielectric Withstand Voltage: By Type Max. overload voltage for 1 minute Thermal Shock: R 0.05% R 0.25% -55C to +150C, 100 cycles R 0.05% R 0.2% Low Temperature Operation: 1 hour, -65C, followed by 45 minutes of RCWV R 0.5% for high power rating Reference Standards: MIL-STD-202, JIS-C 5201-1 Storage Temperature: 253C Humidity < 80%RH 1773272 CIS WR 04/2012 Dimensions are in millimeters Dimensions are shown for For email, phone or live chat, go to: te.com/help and inches unless otherwise reference purposes only. specified. Values in brackets Specifications subject are standard equivalents. to change.
