X-On Electronics has gained recognition as a prominent supplier of UT202F Clamp Multimeters & Accessories across the USA, India, Europe, Australia, and various other global locations. UT202F Clamp Multimeters & Accessories are a product manufactured by Uni-T. We provide cost-effective solutions for Clamp Multimeters & Accessories, ensuring timely deliveries around the world.

UT202F Uni-T

Name: UT202F
Brand: Uni-T
SKU: UT202F_Uni-T
Availability: InStock
Rating: 5 (11 reviews)

Images are for reference only
See Product Specifications

Part No.	UT202F
Manufacturer:	Uni-T
Category:	Clamp Multimeters & Accessories
Description:	AC digital clamp meter; Øcable: 28mm; LCD (6000); I AC: 60mA÷600A
Datasheet:
	Large This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges

Price (USD)

1: USD 38.5434 ea
Line Total: USD 38.54

Availability - 14
Ship by Tue. 26 Nov to Thu. 28 Nov

MOQ: 1 Multiples: 1
Pack Size: 1

UT202F More Buying Options & Price Grid(s)

Please wait...

Availability Price Buy Price Quantity

14

Ship by Tue. 26 Nov to Thu. 28 Nov

MOQ : 1
Multiples : 1

1 : USD 38.5434
2 : USD 36.4413

Specifications

Manufacturer
Uni-T Uni-T

Product Category
Clamp Multimeters & Accessories Clamp Multimeters & Accessories

Category
Clamp Multimeters Accessories Clamp Multimeters Accessories

Standard Equipment
test leads, cover test leads, cover

Conform To The Norm
EN61010 600V CAT II, EN61010 300V CAT III EN61010 600V CAT II, EN61010 300V CAT III

Measuring Instrument Features
autoranging, automatic power - off, HOLD function (for holding display readout), MIN/MAX/REL function, non - contact voltage detector, low battery indicator autoranging, automatic power - off, HOLD function (for holding display readout), MIN/MAX/REL function, non - contact voltage detector, low battery indicator

Ac Voltage Measuring Accuracy
(0 , 8 % + 5 digits) (0 , 8 % + 5 digits)

Dc Voltage Measuring Accuracy
(0 , 5 % + 2 digits) (0 , 5 % + 2 digits)

Kind Of Display Used
LCD (6000) LCD (6000)

Resistance Measuring Accuracy
± (0 , 8 % + 2 digits) ± (0 , 8 % + 2 digits)

Max. Diameter Of Measured Cable
28 mm 28 mm

Frequency Measuring Accuracy
± (1 % + 5 digits) ± (1 % + 5 digits)

Ac Current Measuring Accuracy
(2 % + 10 digits) (2 % + 10 digits)

Capacitance Measuring Accuracy
± (4 % + 5 digits) ± (4 % + 5 digits)

True Effective Value Measurement
True RMS True RMS

Type Of Meter
AC digital clamp meter AC digital clamp meter

Continuity Test
acoustic indication, <10Ω acoustic indication, <10Ω

Test
diodes diodes

Measurement
AC voltage, DC voltage, frequency, capacitance, resistance, AC current, continuity AC voltage, DC voltage, frequency, capacitance, resistance, AC current, continuity

Dimensions
215x63x36mm 215x63x36mm

Weight With Battery
248 g 248 g

Resistance Measuring Range
60 MOhms 60 MOhms

Dc Voltage Measuring Range
600 V 600 V

Ac Voltage Measuring Range
600 V 600 V

Capacitance Measuring Range
60 MF 60 MF

Ac Current Measuring Range
60 mA To 600 A 60 mA To 600 A

Frequency Measuring Range
10Hz...10MHz 10Hz...10MHz

Battery/ Rechargeable Battery
battery R03 AAA 1 , 5V x2 battery R03 AAA 1 , 5V x2

Power Supply
b A ttery R03 A A A 1 , 5 V x2 b A ttery R03 A A A 1 , 5 V x2
