X-On Electronics has gained recognition as a prominent supplier of UT8804E Digital Multimeters across the USA, India, Europe, Australia, and various other global locations. UT8804E Digital Multimeters are a product manufactured by Uni-T. We provide cost-effective solutions for Digital Multimeters, ensuring timely deliveries around the world.

UT8804E Uni-T

Name: UT8804E
Brand: Uni-T
SKU: UT8804E_Uni-T
Availability: InStock
Rating: 5 (11 reviews)

Images are for reference only
See Product Specifications

Part No.	UT8804E
Manufacturer:	Uni-T
Category:	Digital Multimeters
Description:	Benchtop multimeter; LCD 4,3; VDC: 60mV,600mV,6V,60V,600V,1kV
Datasheet:	UT8804E Datasheet (PDF)
	Large This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges

Price (USD)

1: USD 351.1683 ea
Line Total: USD 351.17

Availability - 3
Ship by Wed. 25 Dec to Fri. 27 Dec

MOQ: 1 Multiples: 1
Pack Size: 1

UT8804E More Buying Options & Price Grid(s)

Please wait...

Availability Price Buy Price Quantity

3

Ship by Wed. 25 Dec to Fri. 27 Dec

MOQ : 1
Multiples : 1

1 : USD 351.1683

Specifications

Manufacturer
Uni-T Uni-T

Product Category
Digital Multimeters Digital Multimeters

Kind Of Display Used
LCD 4,3 LCD 4,3

Supply Voltage
100 To 240 VAC 100 To 240 VAC

Interface
USB USB

Illumination
yes yes

Measuring Instrument Features
auto and manual ranging, MIN/MAX/MEAN/REL function, data logger function auto and manual ranging, MIN/MAX/MEAN/REL function, data logger function

Type Of Meter
benchtop multimeter benchtop multimeter

Test
diodes diodes

Continuity Test
acoustic indication acoustic indication

Duty Cycle Factor
10...90 % 10...90 %

Temperature Measuring Range
- 40 To 1000 C - 40 To 1000 C

True Effective Value Measurement
True RMS True RMS

Measurement
AC voltage, DC voltage, temperature, frequency, capacitance, DC current, resistance, AC current, conductance, continuity, pulse width AC voltage, DC voltage, temperature, frequency, capacitance, DC current, resistance, AC current, conductance, continuity, pulse width

Ac Current Measuring Range
10 A , 600 uA , 6 A , 60 mA , 600 mA , 6 mA 10 A , 600 uA , 6 A , 60 mA , 600 mA , 6 mA

Resistance Measuring Range
600 Ohms , 6 kOhms hms , 60 kOhms hms , 600 kOhms hms , 6 MOhms , 60 MOhms 600 Ohms , 6 kOhms hms , 60 kOhms hms , 600 kOhms hms , 6 MOhms , 60 MOhms

Dc Current Measuring Range
600 uA , 10 A , 60 mA , 600 mA , 6 A , 6 mA 600 uA , 10 A , 60 mA , 600 mA , 6 A , 6 mA

Dc Voltage Measuring Range
600 V , 1 kV , 6 V , 60 V , 600 mV , 60 mV 600 V , 1 kV , 6 V , 60 V , 600 mV , 60 mV

Ac Voltage Measuring Range
600 V , 1 kV , 6 V , 60 V , 600 mV , 60 mV 600 V , 1 kV , 6 V , 60 V , 600 mV , 60 mV

Frequency Measuring Range
60 KHz , 6 KHz , 600 Hz , 600 KHz , 6 MHz , 60 MHz , 60 Hz 60 KHz , 6 KHz , 600 Hz , 600 KHz , 6 MHz , 60 MHz , 60 Hz

Capacitance Measuring Range
600 nF , 6 uF , 60 uF , 6 nF , 60 nF , 600 uF , 6 MF , 60 MF 600 nF , 6 uF , 60 uF , 6 nF , 60 nF , 600 uF , 6 MF , 60 MF

Diode Test
3V 3V

Display Parameters
4,83 digit (60000) 4,83 digit (60000)

Frequency Measuring Accuracy
(0.01 % + 5 digit) , ± (0.02 % + 5 digit) @60 Hz (0.01 % + 5 digit) , ± (0.02 % + 5 digit) @60 Hz

Capacitance Measuring Accuracy
± (2 % + 5 digit) , ± (2.5 % + 5 digit) @ 60 nF , ± (5 % + 5 digit) @ 6 MF ± (2 % + 5 digit) , ± (2.5 % + 5 digit) @ 60 nF , ± (5 % + 5 digit) @ 6 MF

Ac Current Measuring Accuracy
(1 % + 20 digit) , ± (0.6 % + 20 digit) , ± (0.6 % + 40 digit) (1 % + 20 digit) , ± (0.6 % + 20 digit) , ± (0.6 % + 40 digit)

Dc Voltage Measuring Accuracy
(0.025 % + 5 digit) , ± (0.003 % + 5 digit) @ (600 V To 1 kV) , ± (0.025 % + 20 digit) @60 mV (0.025 % + 5 digit) , ± (0.003 % + 5 digit) @ (600 V To 1 kV) , ± (0.025 % + 20 digit) @60 mV

Dc Current Measuring Accuracy
(0.08 % + 10 digit) @6000 uA , ± (0.08 % + 20 digit) , ± (0.15 % + 10 digit) @600 mA , ± (0.3 % + 10 digit) @6 A , ± (0.5 % + 10 digit) @10 A (0.08 % + 10 digit) @6000 uA , ± (0.08 % + 20 digit) , ± (0.15 % + 10 digit) @600 mA , ± (0.3 % + 10 digit) @6 A , ± (0.5 % + 10 digit) @10 A

Ac Voltage Measuring Accuracy
(0.3 % + 30 digit) (0.3 % + 30 digit)

Resistance Measuring Accuracy
± (0.05 % + 2 digit) , ± (0.05 % + 10 digit) @ (600 Ohms) , ± (0.3 % + 10 digit) @ (6 MOhms) , ± (2 % + 10 digit) @ (60 MOhms) ± (0.05 % + 2 digit) , ± (0.05 % + 10 digit) @ (600 Ohms) , ± (0.3 % + 10 digit) @ (6 MOhms) , ± (2 % + 10 digit) @ (60 MOhms)

Notes:- Show Stocked Products With Similar Attributes.

UT8804E Alternative Parts
