BCcomponents DATA SHEET 021 ASM Aluminum electrolytic capacitors Axial Standard Miniature Product specification 2000 Jan 18 Supersedes data of March 1998 File under BCcomponents, BC01BCcomponents Product specification Aluminum electrolytic capacitors 021 ASM Axial Standard Miniature FEATURES Polarized aluminum electrolytic capacitors, non-solid electrolyte Axial leads, cylindrical aluminum case, insulated with a blue sleeve Mounting ring version (single ended) not insulated Charge and discharge proof MBB121 Taped versions up to case 15 30 mm available for automatic insertion Fig.1 Component outlines. Miniaturized, high CV-product per unit volume. APPLICATIONS General purpose, industrial, 041/043 ASH automotive, audio-video Coupling, decoupling, smoothing, high voltage filtering, buffering and timing Portable and mobile equipment 021 ASM smaller longer 138 AML (small size, low mass) 117 ASD CV-values life (85 C) (105 C) Low mounting height boards, CCB053 vibration and shock resistant. QUICK REFERENCE DATA DESCRIPTION VALUE Case sizes (D L in mm) 4.5 10 to 10 25 10 30 to 21 40 nom nom Rated capacitance range, C 0.47 to 15000 F R Tolerance on C 20% R Rated voltage range, U 6.3 to 100 V R Category temperature range 40 to +85 C Endurance test at 85 C: U = 6.3 to 25 V 1000 hours 5000 hours R U = 40 to 100 V 2000 hours 5000 hours R Useful life at 85 C 2500 hours 8000 hours Useful life at 40 C, 1.4 I applied 70000 hours 200000 hours R Shelf life at 0 V, 85 C 500 hours 500 hours Based on sectional specification IEC 60384-4/EN130300 Climatic category IEC 60068 40/085/56 2000 Jan 18 2
