041 - 043 ASH Vishay BCcomponents Aluminum Capacitors Axial Standard, High Voltage FEATURES Polarized aluminum electrolytic capacitors, non-solid electrolyte RoHS Axial leads, cylindrical aluminum case, COMPLIANT insulated with a blue sleeve Mounting ring version not available in insulated form Fig.1 Component outlines Taped versions up to case 15 x 30 mm available for 042/043 lighting automatic insertion AMH-ELB 85 C 041/043 ASH applications AHH-ELB 105 C Useful life: 5000 to 15 000 hours at 85 C low voltage High rated voltage: up to 450 V Lead (Pb)-free versions are RoHS compliant 021 ASM APPLICATIONS 138 AML General purpose, industrial, power supply, audio-video Smoothing, filtering, buffering at high voltages QUICK REFERENCE DATA Boards with restricted mounting height, vibration and DESCRIPTION VALUE shock resistant Nominal case sizes 6.5 x 18 10 x 30 ( D x L in mm) to 10 x 25 to 21 x 38 MARKING Rated capacitance range, C 1to220 F R - 10 to + 50 % The capacitors are marked (where possible) with the Tolerance on C R Rated voltage range, U 160 to 450 V following information: R - 40 to + 85 C Rated capacitance (in F) Category temperature range (450 V: - 25 to + 85 C) Tolerance on rated capacitance, code letter in accordance 8000 hours Endurance test at 85 C 2000 hours (450 V: with IEC 60062 (T for - 10 to + 50 %) 5000 hours) Rated voltage (in V) 15 000 hours Useful life at 85 C 5000 hours (450 V: Upper category temperature (85 C) 10 000 hours) Date code, in accordance with IEC 60062 1.8 x I applied: R 1.4 x I R Code indicating factory of origin 240 000 hours Useful life at 40 C applied: (450 V: 120 000 hours Name of manufacturer 160 000 hours) Band to indicate the negative terminal Shelf life at 0 V, 85 C 500 hours 500 hours Based on sectional + sign to identify the positive terminal IEC 60384-4/EN130300 specification Series number (041, 042 or 043) Climatic category IEC 60068 40/085/56 (450 V: 25/085/56) SELECTION CHART FOR C , U AND RELEVANT NOMINAL CASE SIZES ( D x L in mm) R R C U (V) R R (F) 160 250 350 385 400 450 1.0 - - - 6.5 x 18 - - 2.2 - 6.5 x 18 - 8 x 18 - - 4.7 6.5 x 18 8 x 18 10 x 18 10 x 25 - - 6.8 - - 10 x 30 10 x 30 10 x 30 10 x 30 8 x 18 10 x 25 12.5 x 30 12.5 x 30 12.5 x 30 12.5 x 30 10 -10x30 - - - - 15 - 12.5 x 30 12.5 x 30 15 x 30 15 x 30 12.5 x 30 10 x 25 12.5 x 30 15 x 30 18 x 30 18 x 30 15 x 30 22 10 x 30 - - - - - 33 12.5 x 30 15 x 30 18 x 30 18 x 38 18 x 38 18 x 30 47 15 x 30 18 x 30 18 x 38 18 x 38 18 x 38 18 x 38 68 15 x 30 18 x 38 21 x 38 21 x 38 21 x 38 21 x 38 100 18 x 30 21 x 38 - - - - 150 18 x 38 - - - - - 220 21 x 38 - - - - - Document Number: 28329 For technical questions, contact: aluminumcaps1 vishay.com www.vishay.com Revision: 05-May-08 187 041 - 043 ASH Aluminum Capacitors Vishay BCcomponents Axial Standard, High Voltage DIMENSIONS in millimeters AND AVAILABLE FORMS 73 1.6 L D IL 33 1 d D + F F Form BR: Taped on reel case D x L = 6.5 x 18 to 15 x 30 mm Form AA: Axial in box Form BA: Taped in box (ammopack) case D x L = 10 x 30 to 21 x 38 mm case D x L = 6.5 x 18 to 10 x 25 mm Fig.3 Form AA Fig.2 Forms BA and BR Table 1 AXIAL DIMENSIONS in millimeters, MASS AND PACKAGING QUANTITIES AXIAL: FORM AA, BA, AND BR PACKAGING QUANTITIES NOMINAL CASE MASS CASE SIZE FORM FORM FORM CODE (g) dl D L F max. max. min. D X L AA BA BR 6.5 x 18 4 0.8 - 6.9 18.5 25 1.3 - 1000 1000 8 x 18 5 0.8 - 8.5 18.5 25 1.7 - 500 500 10 x 18 6 0.8 - 10.5 18.5 25 2.5 - 500 500 10 x 25 7 0.8 - 10.5 25.5 30 3.3 - 500 500 10 x 30 00 0.8 55 1 10.5 30.5 35 4.8 340 - 500 12.5 x 30 01 0.8 55 1 13.0 30.5 35 7.4 260 - 400 15 x 30 02 0.8 55 1 15.5 30.5 35 11.7 200 - 250 18 x 30 03 0.8 55 1 18.5 30.5 35 12.9 120 - - 18 x 38 04 0.8 34 1 18.5 39.5 44 19.0 125 - - 21 x 38 05 0.8 34 1 21.5 39.5 44 24.0 100 - - Note Detailed tape dimensions see section PACKAGING. D 120 C (3 x) + 0.2 3.6 - 0.2 D3 90 2 (3 x) - L + 0.03 (3 x) 1.05 - 0.1 + 0 1.3 (3 x) d2 Case D x L = 15 x 30 to 21 x 38 mm - 0.05 + 0.1 (3 x) 1.3 Case not insulated (insulation on request) 0 Especially for applications with severe Mounting holes + 1.0 shocks and vibrations 1 - 0.5 Fig.4 Mounting hole digram and outline Form MR: With mounting ring and pins D2 d1 Table 2 MOUNTING RING DIMENSIONS in millimeters, MASS AND PACKAGING QUANTITIES Nominal MOUNTING RING: Form MR CASE MASS PACKAGING CASE SIZE code (g) QUANTITIES d1 d2 D D2 D3 L max. max. max. D x L 15 x 30 02 0.8 1.0 + 0.4 15.5 17.5 16.5 0.2 33 11.7 200 18 x 30 03 0.8 1.0 + 0.4 18.5 19.5 18.5 0.2 33 12.9 240 18 x 38 04 0.8 1.0 + 0.4 18.5 19.5 18.5 0.2 42 19.0 100 21 x 38 05 0.8 1.0 + 0.4 21.5 22.5 21.5 0.2 42 24.0 100 www.vishay.com For technical questions, contact: aluminumcaps1 vishay.com Document Number: 28329 188 Revision: 05-May-08
