MRS16S 1K2 1% Vishay

Phoenix Passive Components PROFESSIONAL/PRECISION FILM RESISTOR MRS FEATURES Metal film technology Precision resistors in small outlines Low noise Non-flammable Defined pulse loading capabilities (MRS25) High stability and uniformity characteristics (MRS25/MRS25 Precision) Various packaging and taping configurations Various forming styles QUICK REFERENCE DATA MRS25 DESCRIPTION MRS16S MRS25 Precision Resistance range 4.99 - 1M 10 - 499k 1 - 10M 10 - 499k 10 - 560k 0.5%, 0.5%, Tolerance and series 1%, E24/E96 1%, E24/E96 0.1%, E192 E24/E96 E24/E96 Maximum dissipation at 0.40W 0.60W 0.125W Tamb. = 70C Limiting voltage (DC or RMS) 200V 350V 300V (1) Rated voltage Pn x R Temperature coefficient 50ppm/C 25ppm/C Basic specification IEC 60115-1 and 60115-4 Climatic category (IEC 60068) 55/155/56 55/125/56 10 - 100 Stability R/Rmax. after: - - 101 - 505k 510 - 560k Load: R 100k 0.5% +0.05 0.5% +0.05 0.25% +0.01 0.1% +0.01 R > 100k 1% +0.05 Climatic tests: R 100k 0.5% +0.05 0.5% +0.05 0.25% +0.01 0.1% +0.01 R > 100k 1% +0.05 Resistance to soldering heat: R 100k 0.1% +0.05 0.1% +0.05 0.05% +0.01 0.02% +0.01 R > 100k 0.25% +0.05 Short time overload 0.25% +0.05 0.25% +0.05 0.05% +0.01 0.05% +0.01 (1) Maximum rated voltage is the limiting voltage MRS PHOENIX DO BRASIL LTDA Revision on 2005/10/27 All rights are reserved. Reproduction whole or in part is Page 1 of 13 prohibited without the written consent of the copyright owner. Phoenix Passive Components TECHNOLOGY A homogeneous film of metal alloy is deposited on a high-grade ceramic body. After a helical groove has been cut in the resistive layer, tinned connecting wires of electrolytic are welded copper to the end-caps. The resistors are coated with a green non-flammable lacquer that provides electrical, mechanical, and climatic protection. The coating is resistant to all cleaning solvents in accordance with MIL-STD 202, method 215 e IEC 68-2-45. MECHANICAL DATA AXIAL STYLE Fig. 1 Table 1. Mechanical Data. WEIGHT PRODUCT L1 L2 D d A B1 - B2 S max. max. max. max. gr/100 pcs 52.5 1.5 11.5 (2.07 0.06) 3.2 3.4 1.9 0.45 0.05 1.2 5.0 0.1 MRS16S (0.13) (0.14) (0.08) (0.018 0.002) (0.05) (0.20 0.01) 26 1.5 8.0 (1.03 0.06) 52.0 1.5 22.0 (2.05 0.06) 6.5 7.5 2.5 0.58 0.05 1.2 5.0 0.1 MRS25 (0.26) (0.3) (0.10) (0.05) (0.023 0.002) (0.20 0.01) 26.0 1.5 16.0 (1.03 0.06) MRS25 6.5 7.5 2.5 0.58 0.05 52.0 1.5 1.2 5.0 0.1 22.0 Precision (0.26) (0.3) (0.10) (0.023 0.002) (2.05 0.06) (0.05) (0.20 0.01) Dimensions unless specified in mm (inches) MRS PHOENIX DO BRASIL LTDA Revision on 2005/10/27 All rights are reserved. Reproduction whole or in part is Page 2 of 13 prohibited without the written consent of the copyright owner.
