E BLK 3M 26001644 Vulcascot

VULCASCOT RUBBER CABLE PROTECTOR SYSTEMS Technical Data Sheet Application: To cover and protect all types of cables found in offices, shops, laboratories, factories exhibition halls, warehouses and anywhere where loose trailing cables are found. Rubber: Natural rubber/SBR blend Hardness: 75 +/- 5% hard Halogens No halogens Fire Retardancy: Fire retardant to BS 476 Part 7 Class 3 and European equivalent DIN Part 1 and Class B1 Conductivity: The material is non-conductive, tested to BS903 Part C5. At 500 volts the reading was in excess of 2000 Mega ohms At 1000 volts the reading was 205 Mega ohms Adhesion: The product can be fixed to the floor using a neoprene contact adhesive or an epoxy resin. All profiles are UV stabilised for extended outdoor life. Featuring: Snap Fit cable insertion VULCASCOT CABLESAFE CRYSCLEAR CABLE PROTECTORS Technical Specification Eye appealing translucent look for designer applications Clear material for easy identification of cables Ideal for covering and protecting LED strips Suitable for covering and protecting telephone, communications, domestic and multiple cables Split the base with round ended scissors for simple application. Typical Performance Values PROPERTY UNIT TEST METHOD VALUE 3 Density* G/cm DIN EN ISO 1183 1.21 2 Tensile Strength N/mm DIN EN ISO 527-2 16 Elongation Break % DIN EN ISO 527-2 >300 Shore Hardness A/3 - DIN 53505/ISO 868 75 o Coldbrittle Temperature C DIN 53372 -33 * without pigmentation
