Data sheet Weidmller Interface GmbH & Co. KG OMNIMATE Signal - series BL/SL 5.08 Klingenbergstrae 16 SL 5.08HC/11/180LF 3.2SN OR BX D-32758 Detmold Germany Fon: +49 5231 1429-0 Fax: +49 5231 14292083 www.weidmueller.com Pin headers in glass-fibre-reinforced plastic with straight wire outlet optimised for wave soldering. The flange variant (F) can be screwed onto the respective counter piece or the circuit board. There is no need for an extra screw to connect the circuit board when the solder flange (LF) version is used. This also protects the solder points from mechanical strain. All pin headers can be manually coded or ordered pre-coded. HC = High Current. General ordering data Type SL 5.08HC/11/180LF 3.2SN OR BX Order No. 1148190000 Version PCB plug-in connector, male header, Solder flange, THT solder connection, 5.08 mm, No. of poles: 11, 180, Solder pin length (l): 3.2 mm, tinned, Orange, Box GTIN (EAN) 4032248931668 Qty. 50 pc(s). Product data IEC: 400 V / 24 A UL: 300 V / 18.5 A Packaging Box Creation date November 23, 2016 8:18:28 AM CET Catalogue status 04.11.2016 / We reserve the right to make technical changes. 1Data sheet Weidmller Interface GmbH & Co. KG OMNIMATE Signal - series BL/SL 5.08 Klingenbergstrae 16 SL 5.08HC/11/180LF 3.2SN OR BX D-32758 Detmold Germany Fon: +49 5231 1429-0 Fax: +49 5231 14292083 www.weidmueller.com Technical data Dimensions and weights Net weight 4.144 g System specifications Product family OMNIMATE Signal - series Mounting onto the PCB BL/SL 5.08 THT solder connection Pitch in mm (P) 5.08 mm Pitch in inches (P) 0.2 inch Outgoing elbow 180 No. of poles 11 Number of solder pins per pole 1 Solder pin length (l) 3.2 mm Solder pin length tolerance +0.1 / -0.3 mm Tolerance of solder pin position 0.15 mm Solder pin dimensions d = 1.2 mm, Octagonal Solder pin dimensions = d tolerance 0 / -0,03 mm Solder eyelet hole diameter (D) 1.3 mm Solder eyelet hole diameter tolerance (D)+ 0,1 mm L1 in mm 50.8 mm L1 in inches 2 inch Number of rows 1 Pin series quantity 1 Can be coded Yes Plugging cycles 25 Packaging Box Material data Insulating material PA GF Colour Orange Colour chart (similar) RAL 2000 Insulating material group II 8 CTI Insulation resistance 550 10 UL 94 flammability rating V-0 Contact material Cu-Leg Contact surface Layer structure of solder connection 1-3 m Ni / 2-4 m Sn tinned matt Layer structure of plug contact 1-3 m Ni / 2-4 m Sn Storage temperature, min. matt -25 C Storage temperature, max. 55 C Max. relative humidity during storage 80 % Operating temperature, min. -50 C Operating temperature, max. 100 C Temperature range, installation, min. -25 C Temperature range, installation, max. 100 C Rated data acc. to IEC tested acc. to standard Rated current, min. no. of poles (Ta = IEC 60664-1, IEC 61984 20C) 24 A Rated current, max. no. of poles (Ta = Rated current, min. no. of poles (Ta = 20C) 19 A 40C) 21 A Rated current, max. no. of poles (Ta = Rated voltage for surge voltage class / 40C) 16.5 A pollution degree II/2 400 V Rated voltage for surge voltage class / Rated voltage for surge voltage class / pollution degree III/2 320 V pollution degree III/3 250 V Rated impulse voltage for surge voltage Rated impulse voltage for surge voltage class/ pollution degree II/2 4 kV class/ pollution degree III/2 4 kV Rated impulse voltage for surge voltage class/ contamination degree III/3 4 kV Rated data acc. to CSA Rated voltage (Use group B) 300 V Rated voltage (use group D) 300 V Rated current (use group B) 18.5 A Rated current (use group D) 18.5 A Creation date November 23, 2016 8:18:28 AM CET Catalogue status 04.11.2016 / We reserve the right to make technical changes. 2
