Model 6104, 6105, 6106 Pomona DMM RF Probe Micro-LC Series FEATURES: Based on the use of SMD components, these narrow-body monolithic probes measure AC voltage of sinusoidal shape between 500Hz and 1GHz within a DMMs normal DC range 10 M Ohm input impedance Conversion factor is 1 VDC for an input of 1 VRMS sine-wave MATERIALS: Scope Probe Body: Probe Tip Brass, Gold Plated Insulation: Thermoplastic Cable: RG 174/U Body: Banana Plug Brass, Nickel Plated Insulation: Thermoplastic, Black and Red All dimensions are in inches. Tolerances (except noted): .xx = .02 (,51 mm), .xxx = .005 (,127 mm). All specifications are to the latest revisions. Specifications are subject to change without notice. Registered trademarks are the property of their respective companies. Made in USA 6/9/99 PomonaACCESS 90807 (800) 444-6785 or (425) 446-6010 Sales: 800-490-2361 Fax: 888-403-3360 SY/EH/LS More drawings available at www.pomonaelectronics.com Technical Assistance: 800-241-2060 C: Laura Goldberg FlukeDataSheet d6104 05 06 2 01.doc Page 1 of 2 Model 6104, 6105, 6106 Pomona DMM RF Probe Micro-LC Series Accessory Kit Kit includes: Sprung Hook Model 5818 BNC Adapter Model 5822 Replacement Tip: Standard Model 6094 Ground Lead, with Minigator Clip Model 5825 Marking: Scope Probe Body: POMONA RATINGS: Electrical: See Table Below: MAX. HF . MODEL BANDWIDTH VOLTAGE INPUT ACTUATING INPUT (Veff) (V) VOLTAGE C(pF) 6104 500Hz 30MHz + 1.5 dB 45 100 0.2 10 6105 100KHz 300MHz + 1.5 dB 30 100 0.35 7 6106 1MHz 1GHz + 2.0 dB 30 100 0.35 6 ORDERING INFORMATION: Model 6104, 6105, 6106 Packaging: One Scope Probe and one Accessory Kit per blister box All dimensions are in inches. Tolerances (except noted): .xx = .02 (,51 mm), .xxx = .005 (,127 mm). All specifications are to the latest revisions. Specifications are subject to change without notice. Registered trademarks are the property of their respective companies. Made in USA 6/9/99 PomonaACCESS 90807 (800) 444-6785 or (425) 446-6010 Sales: 800-490-2361 Fax: 888-403-3360 SY/EH/LS More drawings available at www.pomonaelectronics.com Technical Assistance: 800-241-2060 C: Laura Goldberg FlukeDataSheet d6104 05 06 2 01.doc Page 2 of 2
