WPMDM1500602 / 171050601 3 MagI C Power Module VDRM Variable Step Down Regulator Module 6V 36V / 5A / 0.8V 6V Output DESCRIPTION FEATURES The VDRM series of the MagIC Power Module family Peak efficiency above 90% provides a fully integrated DC-DC power supply including Current capability up to 5A the buck switching regulator and inductor in a package. Input voltage range: 6V to 36V Output voltage range: 0.8V to 6V The 171050601 offers high efficiency and delivers up to Reference accuracy: 2.5% 5A of output current. It operates with an input voltage No minimum load required from 6V up to 36V. It is designed for fast transient Integrated shielded inductor solution for quick time to response. market and ease of use Single exposed pad for best-in-class thermal It is available in an innovative industrial high power performance density TO263-7EP (10.16 x 13.77 x 4.57mm) package Low output voltage ripple (< 10mV ) pp that enhances thermal performance and allows for hand Fixed switching frequency: 812kHz (typ.) or machine soldering. Current Mode control The VDRM regulators have an integrated protection Synchronous operation circuit that guards against thermal overstress and Automatic power saving operation at light load electrical damage by using thermal shut-down, Undervoltage lockout protection (UVLO) overcurrent, short-circuit, overvoltage and undervoltage Adjustable soft-start and voltage tracking protection. Frequency Synchronization with external clock (from 650kHz to 950kHz) Thermal shutdown TYPICAL APPLICATIONS Short circuit protection Cycle-by-cycle current limit Point-of-Load DC-DC applications from 9V, 12V, 18V Output overvoltage protection and 24V industrial rails Package compatible with 171010601, 171012401, Industrial, test & measurement, medical applications 171020601, 171012402, 171030601 and 171032401 System power supplies Operating ambient temperature up to 105C DSPs, FPGAs, MCUs and MPUs supply RoHS and REACh compliant I/O interface power supply Operating junction temp. range: -40 to 125C Mold compound UL 94 Class V0 (flammability testing) certified Complies with EN55032 class B conducted and radiated emissions standard TYPICAL CIRCUIT DIAGRAM 1 7 V VIN VOUT V IN OUT R FBT Module 2 5 SYNC FB C C IN OUT 4 AGND 3 EN PGND SS/TRK EP 6 R FBB GND GND we-online.com Wrth Elektronik eiSos GmbH & Co. KG Data Sheet Rev. 2.0 July 2018 1/56 TO263-7EPWPMDM1500602 / 171050601 3 MagI C Power Module VDRM Variable Step Down Regulator Module PACKAGE EP Exposed Pad = PGND YMLLLLG3 WPMDM 1500602JT 1 2 3 4 5 6 7 7 6 5 4 3 2 1 6 6 7 7 Top View Bottom View MARKING DESCRIPTION Marking Description WE Wrth Elektronik tradename Y Year M Month LLLL Assembly lot code G3 Lead finish code per Jedec Norm (green 3 mat sin) WPMDM Wrth Part Description (part 1) 1500602JT Wrth Part Description (part 2) PIN DESCRIPTION SYMBOL NUMBER TYPE DESCRIPTION The supply input pin is a terminal for an unregulated input voltage source. It is required VIN 1 Power to place the input capacitor nearby the VIN pin and PGND. The Sync input pin allows for synchronization of the PWM operating frequency with an external frequency source. Apply a CMOS logic level square wave with a frequency SYNC 2 Input between 650 kHz and 950 kHz. When not using synchronization connect to ground. The module free running PWM frequency is 812kHz (typical). Connecting this pin to GND disables the device. Connecting this pin to a voltage higher than 1.18V typ. (but <6.5V) or leaving it floating enables the device. This pin EN 3 Input can be used in order to set an external UVLO through a resistor divider. If this pin is left floating the device is always on. The analog ground pin is the reference point for all stated voltages and must be AGND 4 Supply connected to PGND. The feedback pin is internally connected to the regulation circuitry, the over-voltage and short-circuit comparators. The regulation reference point is 0.796V at this input FB 5 Input pin. Connect the feedback resistor divider between the output and AGND with the midpoint at this pin to set the output voltage. The Soft-Start and Tracking pin is to extend the 1.6ms internal soft-start by connecting SS/TRK 6 Input an external soft-start capacitor. To enable voltage tracking connect to an external resistive divider connected to a higher priority supply rail. The output voltage pin is connected to the internal inductor. For the best stability and VOUT 7 Power operation connect the output capacitor between this pin and PGND. Exposed Pad - Main node for switch current of internal low-side MOSFET. Used as PGND EP Power heat sink for power dissipation during operation. Must be electrically connected to pin 4. we-online.com Wrth Elektronik eiSos GmbH & Co. KG Data Sheet Rev. 2.0 July 2018 2/56 VIN SYNC EN AGND FB SS/TRK VOUT VOUT SS/TRK FB AGND EN SYNC VIN
