5 5 +0,2 O 0,97 -0,0 Dimensions: mm Recommended Land Pattern: mm Properties: Properties Value Unit detail B Material Brass suggested non plated solder pad Surface Tin Solder Cream Thickness 120 m Operating Temperature -55 up to +150 C Storage Conditions (in original 5,54 < 40 C < 75 % RH packaging) Moisture Sensitivity Level (MSL) 1 Electrical Properties: 5,54 sectional drawing A-A A Properties Test conditions Value Unit Tol. Rated Current I 20 C 50 A max. R Stencil Suggestion: B 0,5 A Packaging Properties: Packaging Bulk 4,0 5,5 Scale - 3:1 CREATED CHECKED GENERAL TOLERANCE PROJECTION Wrth Elektronik eiSos GmbH & Co. KG METHOD EMC & Inductive Solutions DaSc JuSa DIN ISO 2768-1m Max-Eyth-Str. 1 DESCRIPTION 74638 Waldenburg Germany WP-SMRA REDCUBE SMT Terminals Tel. +49 (0) 79 42 945 - 0 ORDER CODE right angled, M3/ 3.3 with Pin www.we-online.com 7466310 eiSos we-online.com REVISION STATUS DATE (YYYY-MM-DD) BUSINESS UNIT PAGE 002.002 Valid 2018-08-21 eiCan 1/4 This electronic component has been designed and developed for usage in general electronic equipment only. This product is not authorized for use in equipment where a higher safety standard and reliability standard is especially required or where a failure of the product is reasonably expected to cause severe personal injury or death, unless the parties have executed an agreement specifically governing such use. Moreover Wrth Elektronik eiSos GmbH & Co KG products are neither designed nor intended for use in areas such as military, aerospace, aviation, nuclear control, submarine, transportation (automotive control, train control, ship control), transportation signal, disaster prevention, medical, public information network etc.. Wrth Elektronik eiSos GmbH & Co KG must be informed about the intent of such usage before the design-in stage. In addition, sufficient reliability evaluation checks for safety must be performed on every electronic component which is used in electrical circuits that require high safety and reliability functions or performance. R 3,5 4,33 1,0 7,0 O 0,84 3,5 0,5 O 3,3 0,2 3,33 2,0 3,33Classification Reflow Profile for SMT components: Classification Reflow Soldering Profile: Profile Feature Value Preheat Temperature Min 1) T 150 C s min Preheat Temperature Max T 200 C s max T p Preheat Time t from T to T t 60 - 120 seconds T 5C s s min s max s C t p Max. Ramp Up Rate Ramp-up Rate (T to T ) 3 C/ second max. L P Max. Ramp Down Rate Liquidous Temperature T 217 C L Time t maintained above T t 60 - 150 seconds T L L L L t L Peak package body temperature T see table T s max p Preheat Area Time within 5C of actual peak temperaure t 20 - 30 seconds p Ramp-down Rate (T to T ) 6 C/ second max. L P Time 25C to peak temperature 8 minutes max. T s min 1) refer to IPC/JEDEC J-STD-020D refer to IPC/ JEDEC J-STD-020E t S Package Classification Reflow Temperature: Volume mm Volume mm Volume mm Properties <350 350-2000 >2000 25 PB-Free Assembly Package Thickness < 1.6 mm 1) 260 C 260 C 260 C Time 25C to Peak PB-Free Assembly Package Thickness 1.6 mm - 2.5 mm 260 C 250 C 245 C PB-Free Assembly Package Thickness 2.5 mm 250 C 245 C 245 C Time 1) refer to IPC/JEDEC J-STD-020D refer to IPC/ JEDEC J-STD-020E CREATED CHECKED GENERAL TOLERANCE PROJECTION Wrth Elektronik eiSos GmbH & Co. KG METHOD EMC & Inductive Solutions DaSc JuSa DIN ISO 2768-1m Max-Eyth-Str. 1 DESCRIPTION 74638 Waldenburg Germany WP-SMRA REDCUBE SMT Terminals Tel. +49 (0) 79 42 945 - 0 ORDER CODE right angled, M3/ 3.3 with Pin www.we-online.com 7466310 eiSos we-online.com REVISION STATUS DATE (YYYY-MM-DD) BUSINESS UNIT PAGE 002.002 Valid 2018-08-21 eiCan 2/4 This electronic component has been designed and developed for usage in general electronic equipment only. This product is not authorized for use in equipment where a higher safety standard and reliability standard is especially required or where a failure of the product is reasonably expected to cause severe personal injury or death, unless the parties have executed an agreement specifically governing such use. Moreover Wrth Elektronik eiSos GmbH & Co KG products are neither designed nor intended for use in areas such as military, aerospace, aviation, nuclear control, submarine, transportation (automotive control, train control, ship control), transportation signal, disaster prevention, medical, public information network etc.. Wrth Elektronik eiSos GmbH & Co KG must be informed about the intent of such usage before the design-in stage. In addition, sufficient reliability evaluation checks for safety must be performed on every electronic component which is used in electrical circuits that require high safety and reliability functions or performance. Temperature
