ITQ2412SA-H XP Power

DC-DC Converter ITQ Series 6 Watts Single & Dual Outputs xxx Series 4:1 Input Range Operating Temperature 40 C to +100 C 1500 VDC Isolation Optional 3000 VDC Version Fully Regulated Output No Minimum Load Required MTBF 2.8 MHrs 3 Year Warranty Dimensions: ITQ: 0.86 x 0.36 x 0.44 (21.9 x 9.2 x 11.1 mm) Models & Ratings (1) Input Current Maximum (3) Input Voltage Output Voltage Output Current Efficiency Model Number (2) Capacitive Load No Load Full Load 3.3 V 1500 mA 6 mA 261 mA 4700 F 79% ITQ2403SA 5 V 1200 mA 6 mA 298 mA 2200 F 84% ITQ2405SA 9 V 666 mA 6 mA 290 mA 1000 F 86% ITQ2409SA 12 V 500 mA 6 mA 287 mA 470 F 87% ITQ2412SA 9-36 V 15 V 400 mA 6 mA 287 mA 220 F 87% ITQ2415SA 24 V 250 mA 6 mA 287 mA 100 F 87% ITQ2424SA 5 V 600 mA 6 mA 298 mA 330 F 84% ITQ2405S 12 V 250 mA 6 mA 291 mA 220 F 86% ITQ2412S 15 V 200 mA 6 mA 287 mA 100 F 87% ITQ2415S 3.3 V 1500 mA 6 mA 131 mA 4700 F 79% ITQ4803SA 5 V 1200 mA 6 mA 151 mA 2200 F 83% ITQ4805SA 9 V 666 mA 6 mA 147 mA 1000 F 85% ITQ4809SA 12 V 500 mA 6 mA 144 mA 470 F 87% ITQ4812SA 18-75 V 15 V 400 mA 6 mA 144 mA 220 F 87% ITQ4815SA 24 V 250 mA 6 mA 144 mA 100 F 87% ITQ4824SA 5 V 600 mA 6 mA 152 mA 330 F 82% ITQ4805S 12 V 250 mA 6 mA 147 mA 220 F 85% ITQ4812S 15 V 200 mA 6 mA 145 mA 100 F 86% ITQ4815S Notes 1. Input currents measured at nominal input voltage. 2. Maximum capacitive load is per output. 3. For optional 3000VDC isolation add suffix '-H' to model number. www.xppower.com 1DC-DC Converter ITQ Series Input Characteristic Minimum Typical Maximum Units Notes & Conditions 9 36 VDC 24 V nominal Input Voltage Range 18 75 VDC 48 V nominal Input Filter Capacitor Input Reflected Ripple 20/40 mA pk-pk 24/48 V input. Through 12 H inductor and 47 F capacitor 50 VDC for 100 ms 24 V models Input Surge 100 VDC for 100 ms 48 V models Output Characteristic Minimum Typical Maximum Units Notes & Conditions Output Voltage 3.3 24 VDC See Models and Ratings table Initial Set Accuracy 1 % Minimum Load 0A No minimum load required Line Regulation 0.2 % 0.5 % Single output Load Regulation 1 % Dual output On dual output models when one load is varied between Cross Regulation 5 % 25% and 100% and other is fixed at 100% For 3V3 & 5V output models / all other models. Transient Response 5/3 % deviation Recovery within 2% in less than 2ms for a 25% load change Ripple & Noise 125 mV pk-pk 20 MHz bandwidth. Measured using 0.1 F ceramic capacitor Short Circuit Protection Continuous, with auto recovery Maximum Capacitive Load See Models and Ratings table Temperature Coefficient 0.02 %/ C General Characteristic Minimum Typical Maximum Units Notes & Conditions Efficiency 87 % See Models and Ratings table Isolation: Input to Output 1500 VDC 3000 VDC option. Add -H to model number Switching Frequency 580 kHz 9 Isolation Resistance 10 Isolation Capacitance 50 pF 3 Power Density 44 Win Mean Time Between Failure 2.8 MHrs MIL-HDBK-217F, +25 C GB Weight 0.01 (4.8) lb (g) Environmental Characteristic Minimum Typical Maximum Units Notes & Conditions Operating Temperature -40 +100 C Derate from 100% load at +70 C to no load at +100 C Storage Temperature -55 +125 C Case Temperature +100 C Humidity 95 %RH Non-condensing Cooling Natural convection www.xppower.com 2
