Stay Connected with Heyco Liquid Tight Flexible Conduit, Tubing & Fittings Heyco-Flex II Liquid Tight Tubing Flexible, Nonmetallic Liquid Tight Electrical Tubing Maximum flexibility can be used in TRADE PART NO. DESCRIPTION PART DIMENSIONS STANDARD SIZE AB COIL LENGTH extremely tight quarters. Black Outside Inside ft/coil Smooth inside for easier wire pulling. Diameter Diameter Lightweight and lower installed cost. in. mm. in. mm. Integral rigid and flexible 1/4 8449 HF2 1/4 .568 14,4 .395 10,0 100 PVC construction. 3/8 8450 HF2 3/8 .700 17,8 .494 12,5 100 1/2 8451 HF2 1/2 .830 21,1 .632 16,1 100 Use with nylon Heyco-Flex 3/4 8452 HF2 3/4 1.040 26,4 .830 21,1 100 Connectors: Straight, Snap-in, or 1 8453 HF2 1 1.303 33,1 1.054 26,8 100 Sweep. See pages 2-3, 2-4, and 2-5. 1-1/4 8454 HF2 1-1/4 1.645 41,8 1.395 35,4 100 Also use with Quick Twist Fittings. 1-1/2 8455 HF2 1-1/2 1.883 47,8 1.588 40,3 50 See pages 2-7, 2-8, 2-9, and 2-10. 2 8456 HF2 2 2.358 59,9 2.033 51,6 50 1/4 thru 2 trade sizes. Standard color black. Resists corrosion, oil, and water. Consult Heyco for Cut to Length Availability. UV resistant. Suitable for use in high vibration or flexing applications: - Automotive Equipment - Computers and Peripherals B A A B - Fiber Optics - Lab Equipment - Lasers - Office Equipment - Processing Control and Monitoring Equipment - Robotics PN 8340 - White Goods Passes submersion test of 70 psi. Voltage Rating: 300V. Temperature rating 70C (158F). Mounting brackets are available, see page 2-13. Order Part No. 8340, HF-28 Cutting Tool, for cutting Heyco-Flex tubing and conduit cleanly and evenly. Material PVC Certifications Recognized under the Component Program Quick of Underwriters Laboratories File E121095 Certified by Canadian Standards Association File 233010 Flammability Rating VW1 Specs Temperature Rating -.4F (-18C) to 158F (70C) 1-800-526-4182 732-286-1800 (NJ) FAX: 732-244-8843 www.heyco.com 2-2
