Y R T A E T ELECTRICAL TEST TOOLS Phase and Motor Rotation Meters Models 6608, 6609 & 6610 Ideal for installing rotating machinery or motors, and for checking generator output phase direction SPECIFICATIONS MODELS 6608 6609 6610 ELECTRICAL Operating Voltage 40 to 850Vac With leads connected: Static induction between phases 40 to 600Vac between IP 40 phases Rated Frequency Range 15 to 400Hz 45 to 65Hz (Model 6610 only) (Models 6608 Power Supply Self-powered via the 9V Alkaline battery One 9V Alkaline battery & 6609 only) measurement inputs (included) (included) MECHANICAL Dimensions FEATURES 5.1 x 2.7 x 1.3 5.0 x 2.8 x 1.8 (130 x 69 x 32mm) (128 x 72 x 44mm) Voltage sensing detector clips no metal Weight .82 lbs (380g) 4.5 oz (130g) 6 oz (170g) contact points to promote greater safety battery included (Model 6610) ENVIRONMENTAL 14 to 122F Operating Indication of liv e phase presence 32 to 104F (-10 to 50C) Temperature (0 to 40C) or phase absence max. 80% R.H. -4 to 122F -4 to 140F Storage Designed for checking a wider range of (-20 to 50C) (-20C to 60C) Temperature 3-phase power source from 75V to RH < 80% max. 80% R.H. 1000Vca (Model 6610) SAFETY Safety Ratings IEC 61010-1, DIN VDE 0411 Deter mination of a motor s rotation EN 61010-1, IEC 61557-7, DIN VDE 0413-7 direction (Model 6609) EN 61326-1 Tightness: IP 40 (as per IEC 60529 Ed.92) Automatic testing as soon as the Electrical Safety 1000V CAT III 600V CAT III 600V CAT IV instrument is connected T erminals and cables identified by color-coding to simplify connection (test leads are attached to Model 6610) PRODUCT INCLUDES Phase rotation indicators (Model 6608) Phase and motor rotation indicators 6608 & 6609 (Models 6609 & 6610) Carrying case, three test leads (4 ft), three alligator clips and a user manual. Color-coded leads (red, black, blue) and alligator clips (black) Color-coded jac ks for common U.S. phase colors Line supplied - no batter y needed (Model 6608) 6610 Protected internally by high impedance circuit to limit the current to user safe limits Soft carrying case, meter with attached test leads (black, red & blue) with alligator clips, 9V battery and user manual. CATALOG NO. DESCRIPTION 2121.10 Phase Rotation Meter Model 6608 2121.11 Phase & Motor Rotation Meter Model 6609 2121.12 Phase Rotation Meter Model 6610 (Non-contact) Technical Assistance (800) 343-1391 www.aemc.com F I N A S GX-ON Electronics Largest Supplier of Electrical and Electronic Components Click to view similar products for aemc manufacturer: Other Similar products are found below : 2118.79 2118.82 6417 MN261 MN106 2119.02 MD301 SR601 MN103 1017.84 6610 SR752 MS3474W10-6P MS3456L16-10SY-LC SL261 BR07 2118.73 MS3475W14-4S-LC MS3456L20-14SX-LC MS3450W22-2SY-LC MS3475W14-4SW D38999/26WD5PN
