Resistive
Rotary Type Linear Type
Position Sensors
Linear Type
RDC10
The high accuracy space saving design contributes to
reduced weight and size of sets
Typical Specifications
Items Specifications
5V DC
Rated Voltage
50,000 cycles RDC1010
Operating life
200,000 cycles
10k
Total resistance
30 to 85
Operating temperature range
Product Line
Minimum order unit pcs.
Length of lever Length of terminal
Travelmm Linearity Model No. Drawing No.
mm mm
Japan Export
10 1.3 0.8 980 2,940 RDC1010A12 1
14 2,400 4,800
RDC1014A09
22 0.5 4.5 2,100 4,200 RDC1022A05
2 2
32 900 1,800 RDC10320RB
47 4.4 1,000 2,000 RDC1047A03
Notes
1. RDC1014, RDC1022, RDC1032 and RDC1047 Series can be for automotive use.
2. RDC1014, RDC1022, RDC1032 and RDC1047 Series are available in different varieties to the above.
See Product Varieties (P.463).
Packing Specifications
Tray
Number of packages pcs.
Export package
Model No.
measurements mm
1 case /Japan 1 case /export packing
980 2,940 360270230
RDC1010
RDC1014 2,400 4,800 508374272
RDC1022 2,100 4,200 508374302
900 1,800 540360205
RDC1032
RDC1047 1,000 2,000 508374272
Refer to P.463 for product varieties.
Refer to P.466 for product specifications.
Refer to P.467 for soldering conditions.
461Resistive
Rotary Type Linear Type
Position Sensors
R0.85
1.6 Hole
1.6 Hole
1.7
Linear Type
RDC10
Dimensions
Unit:mm
No. Photo Style
RDC1010 C point
4.35 max
13.65 3.65
12 2
10
5
10 min 0.445
1.5
1
0.3 3-0.6
4
1T 3T 2T
4-0.8 7.6
1.3
RDC10
A
Terminal No.
B
2.1
2.52.6 0.4
3T
1T
2T
S+2
4.54.4
S/2+3.4
2 S+9.5 0.3 max.
Dimension
S
S A B C
Mechanical travel Model
RDC1014 14 19 15 10
Caulking
RDC1022 22 19 15 14
height
RDC1032 32 29 25 19
RDC1047 47 37 33 26.5
Sizes in are applicable to
0.4
RDC1047 only.
C
Circuit Diagram
RDC1010 RDC10
2T
3T
3T
1T
1T
2T
462
2.2 hole
1.7 hole
3-1
6.9
1.6
3.6 max.
0.6 max
3.8 max. 2.3 min
6.5
2
6 1.5
3.2
6
4
0.6
5
0.8
2.1 1.3
