MS27656T13B98S Amphenol

Additional MIL-DTL-5015 Connectors Amphenol Aerospace Offered by Amphenol MIL-DTL-5015 and MIL-5015 Type Standard Circular Connector s with solder or crimp (non-rear release) contacts Amphenol has long been the accepted leader in providing MS Stan dard MIL-5015 type connectors These connectors represent well-proven electrical capability at an economical cost for most equipment where durability is important The MS/Standard family of connectors (3100 Series) is a very broad range of product with the following features: Medium to heavy weight cylindrical with resilient inserts Environmental resistant Threaded couplings, single key/keyway shell polarization Operating voltage to 3000 VAC (RMS) at sea level 5 shell styles, 19 shell sizes, 280 contact arrangements Solder or crimp contacts (non-rear-release type), sizes 160 accepting 220 AWG Coaxial or thermocouple contact options Alternate insert positioning MS/Standard 3100 Series, MIL-5015 Type Connectors Hermetic configurations available Zinc alloy plating (cadmium-free) available The 3100 Series has five classes of connectors to meet different requirements Within these connector styles, MIL-C-5015 has been replaced as follows: Environmental classes F and R are updated to and produced in strict accordance to MIL- DTL-5015 Classes A, C and E are still produced, but are no longer listed on the qualified products listing (QPL) Class designations and brief descriptions are as follows: A Solid Shell for general, non-environmental applications C Pressurized for use on pressurized bulkheads or pressure barriers limits air leakage regardless of type and class of plug mated with them E/F Environmental Resisting with Strain Relief designed for applications where the connector will be exposed to mois ture, vibration, and rapid changes in pressure and temperature R Lightweight Environmental Resisting shorter in length, lighter in weight than the E & F classes, the MS-R offers a high degree of reliability under adverse conditions: recommended for new design applications Ask for Amphenol catalog 12-020 which gives detailed information on this family of connectors or visit www amphenol-industrial com MIL-5015 Modifications In order to supplement standard MS shell styles and provide a greater variety of styles for the electrical connector user, there are several MS and MS Modified cylindrical connectors offered by Amphenol These types include flange mount plugs, thru bulkhead receptacles, jam nut receptacles, connectors for potting and connectors designed specifically to terminate jacketed cable Ask for Amphenol catalog 12-021 for detailed information or visit www amphenol-industrial com 97 Series, MIL-5015 Type Connectors The low cost, general duty connector used extensively in the machine tool industry, welding industry and numerous other industrial applications, is the Amphenol 97 Series Offered in non-environmental styles, these con nectors have hard dielectric inserts and threaded coupling They are Underwriters Laboratories Recognized and Canadian Standards Association Certified Recent addition to this family is the 97E environmental styles, still an economical choice The 97E can be used in a variety of industrial applications where environmental sealing is required, such as automotive and robotics Ask for Amphenol catalog 12-022 for detailed information or visit www amphenol-industrial com 97 Series, MIL-5015 Type Connectors 198 Contact Amphenol Aerospace for more infor mation at 800-678-0141 www.amphenol-aerospace.com 5015 Options High Speed EMI Filter Printed 83723 III 26482 38999 Fiber Optics 26500 Pyle Crimp Rear Others Contacts Transient Circuit Board Matrix 2 Matrix Pyle SJT I II Release Matrix III Amphenol MIL-DTL-26500, Pyle TABLE OF CONTENTS MIL-DTL-26500, Pyle Connectors Table of Contents .199 Product Introduction and Options 200 Class Descriptions, Features, Specifications . 201, 202 Insert Arrangements, Alternate Keying . 203, 204 MIL-DTL-26500 Aluminum/Stainless Steel Shell Styles: Threaded Coupling & Bayonet Coupling Quick Reference Charts .205 Ratchet Lock Coupling Quick Reference Charts 206 How to Order, Threaded/Bayonet, Military & Commercial 207, 208 Square Flange Mounted Receptacle, Threaded MS24264, Pyle ZZY 209 Single Hole (D-hole) Mounted Receptacle,Threaded MS24265, Pyle ZZY 210 Straight Plug, Threaded MS24266, Pyle ZZY 211 Square Flange Mounted Receptacle Bayonet, MS24264, Pyle ZZW 212 Single Hole (D-hole) Mounted Receptacle, Bayonet MS24265, Pyle ZZW 213 Straight Plug, Bayonet MS24266, Pyle ZZW 214 Ratchet Lock Plug/New Non-Decoupling Plug, Pyle ZZY .215 Ratchet Lock Plug/New Non-Decoupling Plug, Mating Flange Mounted Receptacle Pyle ZZY 216 MIL-DTL-26500 Firewall Class K Stainless Steel Shell Styles: Threaded Coupling & Bayonet Coupling Quick Reference Charts .217 How to Order Firewall Class K .218 How to Order Firewall Class K, Boeing Company 219 Square Flange Mounted Receptacle, Firewall MS27613K, Pyle FPK Threaded MS27613K, Pyle FYL Bayonet .220 Single Hole (D-hole) Mounted Receptacle Firewall MS27614K, Pyle FPK Threaded MS27614K , Pyle FYL, Bayonet .221 Straight Plug, Firewall MS27615K, Pyle FPK Threaded MS27615K, Pyle FYL, Bayonet Ratchet Lock Plug, Firewall MS27615K, Pyle FPK Threaded .222 MIL-DTL-26500, 48 Series Interconnect Products: Receptacle Short Shirt & Wire Splice Connector . 223, 224 MIL-DTL-26500 Hermetic Receptacle Shell Styles: Pyle ZZL/ZZB Hermetic Receptacles (three styles) Threaded or Bayonet 225 Contacts & Accessories Shielded Coaxial Contacts, Contact Terminating Tools, Assembly Instructions, Cable Supports, Dummy Receptacles, Protection Caps . 226-235 MIL-DTL-26500, Pyle Typical Markets: Military & Commercial Aviation Amphenol High Temperature Applications Aerospace Meets Boeing Specifications Missiles & Ordnance Contact Amphenol Aerospace for more information at 800-678-0141 www.amphenol-aerospace.com 199
