Data Sheet Programmable DC Electronic Loads 8600 Series The 8600 Series programmable DC electronic areas for quick system recall. All load parameters Features loads provide the performance of modular system such as voltage, current, slew rate, and width Voltage range up to 500 V DC electronic loads in a compact benchtop form can be set via the front panel or programmed Current range up to 240 A factor. With fast transient operation speeds and remotely. The 8600 Series provides standard CC/CV/CR/CW operating modes high 16-bit measurement resolution, these USB (USBTMC-compliant), GPIB, or RS-232 16-bit voltage and current measurement standalone DC loads can be used for testing and serial interfaces for remote communication. evaluating a variety of DC sources such as DC system providing 1 mV / 0.1 mA resolution power supplies, DC-DC converters, batteries, To ensure the reliability of your testing, the 8600 Transient mode up to 25 kHz in CC mode battery chargers, and photovoltaic arrays. Series provides a power-on system self-test and List mode function numerous protection features: overtemperature Store and recall up to 100 setups The DC loads can operate in constant current (OTP), overvoltage (OVP), overcurrent (OCP), Adjustable slew rate in CC mode (CC), constant voltage (CV), constant resistance overpower (OPP), and local/remote reverse Flexible triggering options via front panel, (CR), or constant power (CW) mode and be voltage (LRV/RRV) protection. configured to provide a dynamically changing load external input, timer, or bus to the DC source with fast load switching times. Built-in battery test function with voltage level, Versatile internal, external, and remote triggering Special Applications capacity level, and timer stop conditions options allow the dynamic load behavior to be The 8600 Series provides a built-in battery test Test modes to validate the OCP/OPP synchronized with other events. mode to measure the ampere-hour (Ah) protection functions of a power supply characteristic of a battery and a unique CR-LED CR-LED mode to simulate the loading behavior Increase productivity by saving your test mode to simulate the loading behavior of a parameters into any one of the 100 memory of typical LEDs typical LED. Remote sense Analog current control and monitoring Thermostatically controlled fan Model 8600 8601 8602 8610 8612 8614 8616 Standard USB (USBTMC-compliant), RS232, and GPIB interfaces supporting SCPI Power 150 W 250 W 200 W 750 W 750 W 1500 W 1200 W commands for remote control Operating 0 120 V 0 120 V 0 500 V 0 120 V 0 500 V 0 120 V 0 500 V Voltage OVP/OCP/OPP/OTP including local and Rated Current 0 30 A 0 60 A 0 15 A 0 120 A 0 30 A 0 240 A 0 60 A remote reverse voltage (LRV/RRV) protection Compact 19 half-rack form factor allows for side-by-side rack mounting of two units (models 8600, 8601 and 8602) Technical data subject to change www.bkprecision.com B&K Precision Corp. 2015Programmable DC Electronic Loads 8600 Series Models 8600, 8601 & 8602 Bright dual-line display Front panel The 8600 Series display shows both measured input values and set parameters simultaneously. Rotary control knob High current test lead accessory model TLPWR1 Numeric keypad Function keys Cursor keys Load input terminal Intuitive user interface The numeric keys and rotary knob provide a convenient interface for setting the operating mode and desired current, voltage, and resistance levels quickly and precisely. Rear panel RS-232 USB Cooling fan GPIB interface interface interface Current monitor BNC output Outputs a 0-10 V signal that follows 0-full range of the input current. I/O terminal block Line voltage selector External trigger, external analog programming, external input On/Off control, voltage fault pin, and remote sense terminals 2 www.bkprecision.com
