Data Sheet High Voltage Multi-Range DC Power Supplies MR Series USB LAN RS232 GPIB Analog The MR Series high voltage multi-range DC power Features and benefits System Integration supplies deliver up to 5 kW of clean output power in n Output up to 1000 V or 120 A The MR Series offers many features for ATE a compact 2U form factor. These power supplies are n Multi-ranging operation, capable of replacing system and integration applications. suited for both bench use and automated test system multiple fixed range power supplies applications requiring a wide range of voltage and Automation: current. For benchtop applications, this series offers n Compact 2U form factor LXI simplifies integration and system an intuitive user interface for list mode programming n Standard USB (USBTMC-compliant), RS232, development and slew rate adjustments directly from the front GPIB and LXI compliant LAN interfaces Fast command response time (10 ms) panel. Operating software is provided for test TM LabVIEW , IVI-C, and IVI.NET drivers n Galvanically isolated analog control and sequence generation and data logging without the included monitoring interface need to write source code. List mode programming n Protection features: OVP, OCP, OPP, OTP, Built-in web server Integrators will benefit from fast command response foldback protection mode, and key-lock times, excellent regulation, and low noise function Integration: characteristics. In addition, this series supports USB, n Adjustable voltage and current slope (rise and GPIB, LXI compliant LAN, and analog interfaces for 2U form factor saves rack space fall time) remote control and programming. Up to 50 power Simple single-phase AC input supplies can be daisy-chained and controlled from Parallel operation n List mode: 10 user-defined setups with up to one PC, or connect multiple power supplies in Standard USB (USBTMC-compliant), 100 programmable steps each parallel for increased output power. RS232, GPIB and LXI compliant n LED mode to minimize inrush current and LAN interfaces protect LED panels The MR Series includes a built-in SAS (solar array Galvanically isolated analog control and monitoring interface simulator) function to generate I-V curves from the n Built-in SAS function for storage of up to cTUVus certification mark front panel. The optional SAS software allows users 101 I-V curves with Voc, Isc, Vmp, Imp, to simulate various weather conditions and Comprehensive protection features for parameters and 4096-point table the power supply and DUT consistently reproduce I-V curves while monitoring n Remote Sense to compensate for voltage drop Thermostatically-controlled fans help MPPT efficiency data. minimize noise n Master/Slave mode operation provides up to Optional rack-mount kit available 50 kW with 10 units connected in parallel n Control up to 50 power supplies from one PC Model MR3K160120 MR160120 MR25080 MR50040 MR100020 n Soft panel software for remote control, test sequence generation, and data logging included Max. Output Voltage 160 V 160 V 250 V 500 V 1000 V n cTUVus certification mark fulfills CSA and Max. Output Current 120 A 120 A 80 A 40 A 20 A UL safety standards Max. Output Power 3000 W 5000 W Technical data subject to change bkprecision.com B&K Precision Corp. 2021High Voltage Multi-Range DC Power Supplies MR Series Front panel Rotary control knob Bright VFD display Numerical The MR Series displays both measured output Keypad Precisely increment and values and the set parameters simultaneously Input values directly decrement input values Thermostatically controlled fans Cursor keys Front to rear airflow for efficient cooling Quick voltage and current in high density rack environments adjustment on a digit-by-digit basis Rear panel External analog interface Monitor or control USB interface the output using an Set to USBTMC or external voltage or USBVCP (Virtual Output LAN GPIB resistance source COM Port) terminals interface interface Remote sense RS232 Master/Slave Single-phase AC line input terminal interface communication ports This series features a single-phase AC Connect multiple power mains (200 VAC to 240 VAC nominal) supplies for more power connection which is easier to wire and more commonly available than 3-phase AC outlets. High current models Output terminals on 120 A models are enhanced to support connections to larger gauge wire Models MR3K160120 and MR160120 2 bkprecision.com
