Pushbutton F Series Pushbutton Switches Features/Benefits Typical Applications A Up to 10 poles per module Audio selection Various contact terminals Digital equipment interface Various mounting & switch Medical equipment interface ganging configurations Mechanical indicator buttons RoHS compliant Specifications SWITCHING POWER: F module max. AC/DC: Silver: 50 VA/15W, TYPICAL F OPERATING FORCE: 2U: 6.5N (650 grams) 4U: 6.5N Gold: 1 VA/300 mW. (650 grams) 6U: 7.5N (750 grams) 8U: 9.0N (900 grams) 10U: 9.0N (900 grams). SWITCHING VOLTAGE: F module max. AC/DC: Silver: 125/30V, Gold: 50/30 V. EUROPEAN TYPICAL SF OPERATING FORCE: 2U: 3.5N0.5N (350 grams100 grams) 4U: 5N1N (500 SWITCHING CURRENT: F module max. AC/DC: Silver: 0.5A/0.5A, grams100 grams) 6U: 6.5N1N (650 grams100 grams) 8U: Gold: 0.04A/0.01A. 9.0N1N (900 grams100 grams). CARRYING CURRENT: Max at du = 20C: Silver: < 2A, Gold: <0.5A. OPERATING TEMPERATURE RANGE: -40C to 70C. DIELECTRIC STRENGTH (50 Hz, 1 min.): Chassis/contact: 1500V Materials Between contacts: 1500V. 5 HOUSING: Polycarbonate UL 94V-0 or polyester UL 94V-0. OPERATING LIFE OA/EE (24V/200mA): >10 operations GR: >3.5 x 104 operations. ACTUATOR: Polyester UL 94V-0. CONTACT RESISTANCE: Initial: Typical %10 m, max. 20 m MOVABLE CONTACTS: Bimetal brass, silver plated, gold plate After operating life: %100 m over nickel. 9 INSULATION RESISTANCE: 10 between open contacts, STATIONARY CONTACTS & TERMINALS: Brass, silver plated, 9 10 between chassis and contacts. gold plated. CAPACITANCE (at f = 10 kHz): %0.7 pF between 2 contacts. TERMINAL BOARD: Polyester UL 94V-0. TOTAL TRAVEL/LATCHING TRAVEL: 4.7mm/3.3mm (.185 inch/ RETURN SPRING: Music wire130 inch). TERMINAL SEAL: RTV adhesive sealant. All models and options are RoHS compliant and compatible. CHASSIS: Steel. NOTE: All models and options are RoHS compliant and compatible. LOCKOUT PIN: Steel. BLOCKERS: Steel. NOTE: Specifications and materials listed above are for switches with standard options. For information on specific and custom switches, consult Customer Service Center. Build-A-Switch To order, simply select desired option from each category and place in the appropriate box. Available options are shown and described on pages A-88 thru A-95. For additional options not shown in catalog, consult Customer Service Center. If requesting only a switch, select either a North American or European switch as noted below. Chassis and buttons are sold separately. If multiple stations are selected, we will assume all switches are the same unless noted otherwise. North American Order Code - Switch Only Designation F F Series Terminal Sealing Contact Material FLT Light touch F series (NONE) None (NONE) Silver, AG ZF Central mounted F series TB Top/bottom AU Gold Contact Arrangement Terminal Style 2U 2PDT (NONE) Solder lugs & PC pins Mechanical Function Dress nut* 4U 4PDT 01A Cut solder lugs OA Momentary *Central mounted F series only 6U 6PDT 01B Cut PC pins, for other configurations, EE Alternate (push-push) 8U SPDT consult factory GR Interlock (NONE) No dress nut 10U 1OPDT Electrical Function AOR Central release B Black (NONE) BBM Break-Before-Make OASP Momentary with lockout C Chrome M MBB (special) Make-Before-Break GRSP Interlock with lockout Dimensions are shown: Inches (mm) Specifications and dimensions subject to change www.ck-components.com A-87 F Series Pushbutton Switches A European Order Code - Switch Only Designation Terminal Style Contact Material SF F Series (NONE) Solder lugs & (NONE) Silver, AG ZF Central mounted F series PC pins P Gold Contact Arrangement LB Cut solder lugs Dress nut* 2U 2PDT PB Cut PC pins, for other Mechanical Function *Central mounted F series only 4U 4PDT configurations, OA Momentary 6U 6PDT consult factory EE Alternate (push-push) (NONE) No dress nut 8U SPDT GR Interlock Electrical Function B Black (NONE) BBM C Chrome *Minimum order quantities apply. Order Code - Buttons Solid Buttons Mechanical Indicator Buttons Style Style Button Color F01 FMR Shell Color F01 FA100 01 Black F02 FG* F02 FA101 01 Black 02 White F12 FSC F07 FA120 03 Red Out Position Color F13 FSD F08 FA2O1 04 Light gray 01 Black F14 FU12 F11 FA200* F15 FSB F16 FE In Position Color F19 FA 02 White F21 F001 06 Yellow 07 Blue 08 Green *Button options for central mounting configurations, 12 Orange use FG for central mount with chrome dress nut, use FA200 for central mount with black dress nut. BUTTON REMOVAL A button of a push-push switch should only be removed in the OFF non-latching position. Order Code - Chassis To order a switch with chassis, create the switch part number listed above and add the Chassis part number configurator information at the end of the part number. Note: We do not guarantee or recommend interlocking beyond 10 stations. C No. of Stations Special Acknowledgements 01 thru 23 Comes with standard Spacing between Stations See note .094 (2,4mm) mounting holes 00 Single station Note: Single station chassis 10 10mm available with special mounting 12.5 12.5mm configurations, consult factory. 15 15mm 17.5 17.5mm *Minimum order quantities apply. 20 20mm Dimensions are shown: Inches (mm) Specifications and dimensions subject to change www.ck-components.com A-88 Pushbutton
